Image preview - the first page of the document
ktc2876


>> Download ktc2876 documenatation <<

Text preview - extract from the document
                                     SEMICONDUCTOR                                                                         KTC2876
                                                                                                           SILICON NPN TRANSISTOR
                                            TECHNICAL DATA                                                 EPITAXIAL PLANAR TYPE

  FOR MUTING AND SWITCHING APPLICATION.

  FEATURES
                                                                                                       B
    High Emitter-Base Voltage : VEBO=25V(Min.)
    High Reverse hFE




                                                                                                                           A
       : Reverse hFE=150(Typ.) (VCE=-2V, IC=-4mA)
                                                                                                                                         O   DIM MILLIMETERS




                                                                                                                       F
    Low on Resistance : RON=1 (Typ.), (IB=5mA)                                                                                                A   3.20 MAX
                                                                                           H                       M                          B   4.30 MAX
                                                                                                                                              C   0.55 MAX




                                                                                                                           G
                                                                                                                                              D        _
                                                                                                                                                  2.40 + 0.15
                                                                                                                                              E      1.27
                                                                                                                                              F      2.30
                                                                                           C                                                           _
                                                                                                                                              G   14.00+ 0.50
  MAXIMUM RATING (Ta=25                 )                                                                                                     H   0.60 MAX
                                                                                                                                              J      1.05
                                                                                                   E       E
              CHARACTERISTIC                 SYMBOL         RATING      UNIT                                                                  K      1.45
                                                                                                                                              L       25
                                              VCBO




                                                                                       J
   Collector-Base Voltage                                     50         V                                                                    M      0.80




                                                                                                                           D
                                                                                                                       K
                                                                                               1       2       3   N                          N   0.55 MAX
   Collector-Emitter Voltage                  VCEO            20         V                                                                    O      0.75
                                                                                               L

   Emitter-Base Voltage                       VEBO            25         V                                     1. EMITTER
                                                                                                               2. COLLECTOR
   Collector Current                               IC         300       mA                                     3. BASE

   Base Current                                    IB         60        mA
   Collector Power Dissipation                  PC            400       mW                                                     TO-92M
   Junction Temperature                            Tj         150
   Storage Temperature Range                   Tstg         -55 150




  ELECTRICAL CHARACTERISTICS (Ta=25                     )
              CHARACTERISTIC                 SYMBOL                   TEST CONDITION                               MIN.          TYP.        MAX.       UNIT
   Collector Cut-off Current                  ICBO      VCB=50V, IE=0                                                  -           -           0.1         A
   Emitter Cut-off Current                    IEBO      VEB=25V, IC=0                                                  -           -           0.1         A
   DC Current Gain (Note)                     hFE *     VCE=2V, IC=4mA                                             200             -          1200
   Collector-Emitter Saturation Voltage      VCE(sat)   IC=30mA, IB=3mA                                                -         0.042         0.1        V
   Base-Emitter Voltage                       VBE       VCE=2V, IC=4mA                                                 -         0.61           -         V
   Transition Frequency                        fT       VCE=6V, IC=4mA                                                 -          30            -        MHz
   Collector Output Capacitance                Cob      VCB=10V, IE=0, f=1MHz                                          -          4.8           7         pF

                         Turn-on Time          tON                                                                     -         160            -

   Switching
                         Storage Time          tstg                                                                    -         500            -         nS
   Time

                         Fall Time                 tf                                                                  -         130            -

  *Note) : hFE Classification   A:200~700,    B: 350 1200,     C: 700   1200




2007. 5. 23                      Revision No : 1                                                                                                                1/3
                                KTC2876




2007. 5. 23   Revision No : 1             2/3
                                KTC2876




2007. 5. 23   Revision No : 1             3/3
