Image preview - the first page of the document
>> Download ktc2036 documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KTC2036
TECHNICAL DATA EPITAXIAL PLANAR NPN TRANSISTOR
GENERAL PURPOSE APPLICATION.
FEATURES
Low Collector Saturation Voltage
: VCE(sat)=1.0V(Max) at IC=2A, IB=0.2A
MAXIMUM RATING (Ta=25 )
CHARACTERISTIC SYMBOL RATING UNIT
Collector-Base Voltage VCBO 80 V
VCEO 60
Collector-Emitter Voltage V
VCER 100
Emitter-Base Voltage VEBO 10 V
Collector Current IC 3 A
Base Current IB 0.5 A
Collector Power Ta=25 2
PC W
Dissipation Tc=25 20
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
ELECTRICAL CHARA CTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector Cut-off Current ICBO VCB=80V, IE=0 - - 1 A
Emitter Cut-off Current IEBO VEB=10V, IC=0 - - 1 A
Collector-Emitter Breakdown Voltage V(BR)CEO IC=50mA, IB=0 60 - - V
DC Current Gain hFE (Note) VCE=5V, IC=0.5A 100 - 300
Collector Emitter Saturation Voltage VCE(sat) IC=2A, IB=0.2A - 0.25 1.0 V
Base-Emitter Voltage VBE VCE=5V, IC=0.5A - 0.7 1.0 V
Transition Frequency fT VCE=5V, IC=0.5A - 30 - MHz
Collector Output Capacitance Cob VCB=10V, IE=0, f=1MHz - 35 - pF
Turn-on Time ton - 0.65 -
Switching Time Storage Time tstg - 1.3 - S
Fall Time tf - 0.65 -
Note : hFE Classification Y:100~200, GR:150~300
2010. 7. 5 Revision No : 0 1/2
KTC2036
IC - V CE Pc - Ta
3.0 40
COLLECTOR POWER DISSIPATION PC (W)
90 60 1 Tc=Ta
COLLECTOR CURRENT I C (A)
80 50 INFINITE HEAT SINK
2.5 70 35 2 300x300x2mm Al
40
HEAT SINK
2.0 30 30 3 200x200x2mm Al
HEAT SINK
20 1
25 4 100x100x1mm Al
1.5 HEAT SINK
I B =10mA 5 100x100x1mm Fe
20 2
1.0 HEAT SINK
3
6 50x50x1mm Al
15 HEAT SINK
0.5 COMMON EMITTER 4
Tc=25 C 7 50x50x1mm Fe
10 5
0 HEAT SINK
0 6
8 NO HEAT
0 1 2 3 4 5 6 7 8 5 7
SINK
8
COLLECTOR-EMITTER VOLTAGE VCE (V) 0
0 25 50 75 100 125 150 175 200
AMBIENT TEMPERATURE Ta ( C)
h FE - I C SAFE OPERATING AREA
300 10
I C MAX.(PULSED)*
Tc=100 C 5 I C MAX.
COLLECTOR CURRENT I C (A)
DC CURRENT GAIN h FE
C
Tc=25 (CONTINUOUS)
C 3
Tc=-25
1m
100
S*
10
DC
mS
OP
10
*
50
ER
0m N
AT
1
S*
IO
30
0.5
COMMON EMITTER * SINGLE NONREPETITIVE
VCEO MAX.
VCE =5V 0.3 PULSE Tc=25 C
10 CURVES MUST BE DERATED
0.02 0.05 0.1 0.3 1 3 10 LINEARLY WITH INCREASE
IN TEMPERATURE
COLLECTOR CURRENT IC (A) 0.1
1 3 5 10 30 50 100
COLLECTOR-EMITTER VOLTAGE VCE (V)
VCE(sat) - I C
1
COLLECTOR-EMITTER SATURATION
COMMON EMITTER
I C /I B =10
0.5
VOLTAGE VCE(sat) (V)
0.3
C
0.1 100
Tc=
0.05 Tc=25 C
Tc=-25 C
0.03
0.02 0.05 0.1 0.3 1 3 5 10
COLLECTOR CURRENT I C (A)
2010. 7. 5 Revision No : 0 2/2
