Image preview - the first page of the document
>> Download ktc3207t documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KTC3207T
TECHNICAL DATA TRIPLE DIFFUSED NPN TRANSISTOR
HIGH VOLTAGE SWITCHING APPLICATION.
COLOR TV HORIZONTAL DRIVER APPLICATION.
COLOR TV CHROMA OUTPUT APPLICATION. E
K B
DIM MILLIMETERS
FEATURES A _
2.9 + 0.2
High Voltage : V(BR)CEO=300V B 1.6+0.2/-0.1
C _
0.70 + 0.05
2
Small Collector Output Capacitance : Cob=3.0pF(Typ.)
G
3 _
D 0.4 + 0.1
D
A
E 2.8+0.2/-0.3
F
Complementary to KTA1073T. F _
1.9 + 0.2
1
G
G 0.95
H _
0.16 + 0.05
I 0.00-0.10
J 0.25+0.25/-0.15
K 0.60
MAXIMUM RATINGS (Ta=25 )
C
L 0.55
L
H
I
CHARACTERISTIC SYMBOL RATING UNIT J J
Collector-Base Voltage VCBO 300 V
1. EMITTER
Collector-Emitter Voltage VCEO 300 V 2. BASE
3. COLLECTOR
Emitter-Base Voltage VEBO 6 V
Collector Current IC 100 mA
Base Current IB 50 mA
TSM
Collector Power Dissipation PC * 0.9 W
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
* Package mounted on a ceramic board (600 0.8 )
Marking
h FE Rank Lot No.
Type Name
LX
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector Cut-off Current ICBO VCB=240V, IE=0 - - 1.0 A
Emitter Cut-off Current IEBO VEB=6V, IC=0 - - 1.0 A
hFE(1) VCE=10V, IC=1mA 30 - -
DC Current Gain
hFE(2) (Note) VCE=10V, IC=20mA 50 - 200
Collector-Emitter Saturation Voltage VCE(sat) IC=10mA, IB=1mA - - 1.0 V
Base-Emitter Saturation Voltage VBE(sat) IC=10mA, IB=1mA - - 1.0 V
Transition Frequency fT VCE=10V, IC=20mA 50 - - MHz
Collector Output Capacitance Cob VCB=20V, IE=0, f=1MHz - 3.0 - pF
Note : hFE(2) Classification O:50 150, Y:100 200
2002. 11. 7 Revision No : 1 1/3
KTC3207T
I C - V CE I C - V BE
120 100
COMMON EMITTER COMMON
COLLECTOR CURRENT IC (mA)
COLLECTOR CURRENT I C (mA)
6 Ta=25 C
100 EMITTER
4 3 80
2 VCE =10V
C
0 C
Ta=-25 C
80
Ta=25
1 60
Ta=10
60 0.6
40
40 0.4
I B =0.2mA 20
20
0
0 0
0 4 8 12 16 20 24 0.2 0.4 0.6 0.8 1.0 1.2
COLLECTOR-EMITTER VOLTAGE VCE (V) BASE-EMITTER VOLTAGE V BE (V)
h FE - I C h FE - I C
500 500
COMMON EMITTER COMMON EMITTER
300 300
Ta=25 C VCE =10V
DC CURRENT GAIN h FE
DC CURRENT GAIN h FE
VC
Ta=100 C
100 100
E
=2 CE = V
Ta=25 C
0V 10V
V
V CE
50 50 Ta=-25 C
=5
30 30
10 10
0.3 0.5 1 3 5 10 30 50 100 0.3 0.5 1 3 5 10 30 50 100
COLLECTOR CURRENT I C (mA) COLLECTOR CURRENT I C (mA)
VCE(sat) - I C VCE(sat) - I C
COLLECTOR-EMITTER SATURATION
5 5
COLLECTOR-EMITTER SATURATION
COMMON EMITTER COMMON EMITTER
3 3
Ta=25 C I C /I B =5
VOLTAGE V CE(sat) (V)
VOLTAGE VCE(sat) (V)
1 1
0.5 0.5
0.3 0.3
I C /I B =10 =5 Ta=100 C
I C /I B
0.1 I C /I B =2 0.1 Ta=25 C
Ta=-25 C
0.05 0.05
0.3 0.5 1 3 5 10 30 50 100 0.3 0.5 1 3 5 10 30 50 100
COLLECTOR CURRENT I C (mA) COLLECTOR CURRENT I C (mA)
2002. 11. 7 Revision No : 1 2/3
KTC3207T
VBE(sat) - I C fT - IC
5 500
TRANSITION FREQUENCY f T (MHz)
COMMON EMITTER COMMON EMITTER
BASE-EMITTER SATURATION
3 I C /IB =5 300
Ta=25 C
VOLTAGE VBE(sat) (V)
Ta=25 C
1 100
VC
E
=2
VC
VC
0
0.5 50
V
E
E
=1
=5
0V
0.3 30
V
0.1 10
0.3 1 3 5 10 30 50 100 0.3 1 3 5 10 30 50 100
COLLECTOR CURRENT I C (mA) COLLECTOR CURRENT I C (mA)
C ob - VCB Pc - Ta
COLLECTOR OUTPUT CAPACITANCE
50 1.4
COLLECTOR POWER DISSIPATION
I E =0 MOUNTED ON A
30 f=1MHz
1.2 CERAMIC BOARD
Ta=25 C
(600mm 2 0.8mm)
1.0
C ob (pF)
10 0.8
PC (W)
5 0.6
3 0.4
0.2
1 0
1 3 5 10 30 50 100 300 0 20 40 60 80 100 120 140 160
COLLECTOR-BASE VOLTAGE VCB (V) AMBIENT TEMPERATURE Ta ( C)
2002. 11. 7 Revision No : 1 3/3
