Image preview - the first page of the document
>> Download ktc4520f documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KTC4520F
TECHNICAL DATA TRIPLE DIFFUSED NPN TRANSISTOR
SWITCHING REGULATOR APPLICATION.
HIGH VOLTAGE SWITCHING APPLICATION.
A C
DIM MILLIMETERS
FEATURES S
F
A _
10.0 + 0.3
P
B _
15.0 + 0.3
Excellent Switching Times. E
C _
2.70 + 0.3
B
: ton=0.5 S(Max.), tf=0.3 S(Max.), at IC=2A. D 0.76+0.09/-0.05
G
E _
3.2 + 0.2
High Collector Voltage : VCEO=500V. F _
3.0 + 0.3
G _
12.0 + 0.3
H 0.5+0.1/-0.05
L L J _
13.6 + 0.5
R
K
K _
3.7 + 0.2
L 1.2+0.25/-0.1
M
M 1.5+0.25/-0.1
J
MAXIMUM RATING (Ta=25 ) D D N _
2.54 + 0.1
P _
6.8 + 0.1
CHARACTERISTIC SYMBOL RATING UNIT Q _
4.5 + 0.2
R _
2.6 + 0.2
Collector-Base Voltage VCBO 800 V N N H S 0.5 Typ
Collector-Emitter Voltage VCEO 500 V
Emitter-Base Voltage VEBO 7 V
3
1. BASE
1 2
Q
DC IC 3 2. COLLECTOR
Collector Current A 3. EMITTER
Pulse ICP 6
Base Current IB 1 A
TO-220IS
Collector Power Dissipation (Tc=25 ) PC 30 W
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector Cut-off Current ICBO VCB=500V, IE=0 - - 10 A
Emitter Cut-off Current IEBO VEB=5V, IC=0 - - 10 A
Collector-Emitter Sustaning Voltage VCEX(SUS) IC=1.5A, IB1=-IB2=0.6A L=2mH, Clamped 500 - - V
Collector-Emitter Saturation Voltage VCE(sat) IC=1.5A, IB=0.3A - - 1 V
Base-Emitter Saturation Voltage VBE(sat) IC=1.5A, IB=0.3A - - 1.5 V
hFE (1) (Note) VCE=5V, IC=0.3A 15 - 50
DC Current Gain
hFE (2) VCE=5V, IC=1.5A 8 - -
Collector Output Capacitance Cob VCB=10V, IE=0, f=1MHz - 50 - pF
Transition Frequency fT VCE=10V, IC=0.3A - 18 - MHz
Turn On Time ton - - 0.5
Switching
Storage Time tstg - - 3 S
Time
Fall Time tf - - 0.3
Note : hFE (1) Classification R:15 30, O:20 40, Y:30 50
2010. 6. 17 Revision No : 1 1/3
KTC4520F
I C - VBE V CE(sat), V BE(sat) - I C
STATURATION VOLTAGE V BE(sat) , VCE(sat) (V)
10
4 I C /I B =5
VCE =5V 5
COLLECTOR CURRENT I C (A)
2
3 V BE(sat)
1
0.5
2
0.2
0.1 V CE(sat)
1
0.05
0 0.02
0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.8 0.01
0.02 0.05 0.1 0.2 0.5 1 2 5 10
BASE-EMITTER VOLTAGE VBE (V)
COLLECTOR CURRENT I C (A)
I C - V CE
h FE - I C
5
1000
V CE =5V
500
COLLECTOR CURRENT I C (A)
4
DC CURRENT GAIN h FE
200
100 A
3 I B =500m
50 I B =400mA
I =300mA
B
20 2 I B =200mA
10 I B =100mA
5 1 I B =50mA
I B =20mA
2 I B =0mA
0
1 1 2 3 4 5 6 7 8 9 10
0.01 0.02 0.05 0.1 0.2 0.5 1 2 5 10
COLLECTOR CURRENT I C (A) COLLECTOR-EMITTER VOLTAGE V CE (V)
SAFE OPERATING AREA REVERSE BIAS SAFE OPERATING AREA
10 10
I C MAX.(Pulse)*
*5
5 IC MAX. (CONTINUOUS) *1 *
0m 1mS
