Image preview - the first page of the document
ktc4666


>> Download ktc4666 documenatation <<

Text preview - extract from the document
                                    SEMICONDUCTOR                                                                                     KTC4666
                                             TECHNICAL DATA                                                 EPITAXIAL PLANAR NPN TRANSISTOR


  LOW NOISE AMPLIFIER APPLICATION.


                                                                                                                                  E
  FEATURE                                                                                                             M           B    M

    High hFE : hFE=600 3600.                                                                                                                                DIM       MILLIMETERS
                                                                                                                                                             A               _
                                                                                                                                                                        2.00 + 0.20
                                                                                                                                                        D
    Noise Figure : 0.5dB(Typ.) at f=100kHz.                                                                              2                                  B                _
                                                                                                                                                                        1.25 + 0.15
                                                                                                                                                                             _




                                                                                                        A
                                                                                                                                                                        0.90 + 0.10




                                                                                                             J
                                                                                                                                                            C
                                                                                                                         1             3




                                                                                                                 G
                                                                                                                                                            D         0.3+0.10/-0.05
                                                                                                                                                            E                _
                                                                                                                                                                        2.10 + 0.20
                                                                                                                                                            G              0.65
                                                                                                                                                            H         0.15+0.1/-0.06
                                                                                                                                                            J              1.30
  MAXIMUM RATING (Ta=25                  )                                                                                                                  K           0.00-0.10
                                                                                                                                                            L              0.70
              CHARACTERISTIC                 SYMBOL               RATING            UNIT




                                                                                                            C
                                                                                                                                                    H                        _




                                                                                                                 L
                                                                                                                                                            M           0.42 + 0.10
                                                                                                                                                            N            0.10 MIN
   Collector-Base Voltage                      VCBO                       60               V                         N
                                                                                                                               K
                                                                                                                                           N


   Collector-Emitter Voltage                   VCEO                       50               V
                                                                                                                     1. EMITTER
   Emitter-Base Voltage                        VEBO                       8                V
                                                                                                                     2. BASE
   Collector Current                             IC                   150            mA                              3. COLLECTOR

   Base Current                                  IB                       30         mA
   Collector Power Dissipation                  PC                    200            mW
   Junction Temperature                          Tj                   150
