Image preview - the first page of the document



>> Download ktc601f documenatation <<

Text preview - extract from the document

                                    SEMICONDUCTOR                                                             KTC601F
                                           TECHNICAL DATA                                            EPITAXIAL PLANAR NPN TRANSISTOR


  GENERAL PURPOSE APPLICATION.
  SWITCHING APPLICATION.                                                                              TENTATIVE
  FEATURES
    Thin fine pitch super mini 5pin.
    Excellent temperature response between these 2 transistor.
    High pairing property in hFE.
    The follwing characteristics are common for Q1, Q2.




  MAXIMUM RATING (Ta=25                )
         CHARACTERISTIC                SYMBOL              RATING           UNIT
   Collector-Base Voltage                  VCBO                   60         V
   Collector-Emitter Voltage               VCEO                   50         V
   Emitter-Base Voltage                    VEBO                   5          V
   Collector Current                        IC                150           mA
   Base Current                             IB                    30        mA
   Collector Power Dissipation             PC *               100           mW
   Junction Temperature                     Tj                150
   Storage Temperature Range               Tstg            -55 150
  * Total Rating


  ELECTRICAL CHARACTERISTICS (Ta=25                           )
              CHARACTERISTIC                      SYMBOL                         TEST CONDITION              MIN.   TYP.   MAX.   UNIT.
   Collector Cut-off Current                        ICBO               VCB=60V, IE=0                           -     -      0.1
   Emitter Cut-off Current                          IEBO               VEB=5V, IC=0                            -     -      0.1
   DC Current Gain                                hFE (Note)           VCE=6V, IC=2                           120    -     400
   Collector-Emitter Saturation Voltage            VCE(sat)            IC=100 , IB=10                          -    0.1    0.25    V
   Transition Frequency                               fT               VCE=10V, IC=1                          80     -       -
   Collector Output Capacitance                      Cob               VCB=10V, IE=0, f=1                      -     2      3.5
   Noise Figure                                      NF                VCE=6V, IC=0.1 , f=1      , Rg=10       -    1.0     10
  Note : hFE Classification Y(4):120 240, GR(6):200 400


                          EQUIVALENT CIRCUIT (TOP VIEW)
                                                                                       Marking




2005. 12. 6                      Revision No : 0                                                                                          1/3
                                KTC601F




2005. 12. 6   Revision No : 0             2/3
                                KTC601F




2005. 12. 6   Revision No : 0             3/3
