Image preview - the first page of the document
ktc9016


>> Download ktc9016 documenatation <<

Text preview - extract from the document
                                   SEMICONDUCTOR                                                                                            KTC9016
                                               TECHNICAL DATA                                               EPITAXIAL PLANAR NPN TRANSISTOR


  HIGH FREQUENCY LOW NOISE AMPLIFIER APPLICATION.
  HF, VHF BAND AMPLIFIER APPLICATION.
                                                                                                                        B                            C

  FEATURES
    Small Reverse Transfer Capacitance




                                                                                                                                            A
      : Cre=0.65pF(Typ.).
    Low Noise Figure :NF=2.2dB(Typ.) at f=100MHz.                                                                                                        N     DIM    MILLIMETERS
                                                                                                                                        E                       A      4.70 MAX
                                                                                                                K
                                                                                                                                G                               B      4.80 MAX
                                                                                                                D                                               C      3.70 MAX




                                                                                                                                            J
                                                                                                                                                                D          0.45
                                                                                                                                                                E          1.00
                                                                                                                                                                F          1.27
  MAXIMUM RATING (Ta=25                   )                                                                                                                     G          0.85
                                                                                                                                                                H          0.45
                                                                                                                                                                             _
              CHARACTERISTIC                    SYMBOL                 RATING     UNIT                                      H                                   J      14.00 + 0.50
                                                                                                                F                   F                           K      0.55 MAX
                                                                                                                                                                L          2.30
   Collector-Base Voltage                            VCBO                40           V                                                                         M      0.45 MAX
                                                                                                                                                                N         1.00
   Collector-Emitter Voltage                         VCEO                30           V




                                                                                                                                            C
                                                                                                                    1   2   3




                                                                                                            L




                                                                                                                                        M
   Emitter-Base Voltage                              VEBO                 4           V                                                         1. EMITTER
                                                                                                                                                2. BASE
   Collector Current                                  IC                 20           mA                                                        3. COLLECTOR

   Emitter Current                                    IE                 -20          mA
   Collector Power Dissipation                        PC                 625          mW                                                        TO-92
   Junction Temperature                               Tj                 150
   Storage Temperature Range                         Tstg              -55 150




  ELECTRICAL CHARACTERISTICS (Ta=25                                )
               CHARACTERISTIC                         SYMBOL                          TEST CONDITION                            MIN.              TYP.         MAX.         UNIT
   Collector Cut-off Current                                ICBO          VCB=40V, IE=0                                                 -           -           0.1            A
   Emitter Cut-off Current                                  IEBO          VEB=4V, IC=0                                                  -           -           0.1            A
   DC Current Gain                                    hFE (Note)          VCE=5V, IC=1mA                                                40          -           198
   Reverse Transfer Capacitance                             Cre           VCE=6V, f=1MHz, IE=0                                          -           -           1.0           pF
   Transition Frequency                                      fT           VCE=6V, IC=1mA, f=200MHz                                  260             -            -           MHz
   Collector-Base Time Constant                        CC rbb'            VCE=6V, IE=-1mA, f=30MHz                                      -           -           30            pS
   Noise Figure                                             NF                                                                          -          2.2          4.0           dB
                                                                          VCE=6V, IE=-1mA, f=100MHz
   Power Gain                                               Gpe                                                                         15          -            -            dB
  Note) hFE Classification E:40     59,       F:54    80,    G:72 108,         H:97    146,   I:130   198




1994. 5. 11                       Revision No : 0                                                                                                                                     1/1
