Image preview - the first page of the document
ktc9016s


>> Download ktc9016s documenatation <<

Text preview - extract from the document
                                  SEMICONDUCTOR                                                                       KTC9016S
                                            TECHNICAL DATA                                         EPITAXIAL PLANAR NPN TRANSISTOR


  HIGH FREQUENCY LOW NOISE AMPLIFIER APPLICATION.
  HF, VHF BAND AMPLIFIER APPLICATION.
                                                                                                                          E
  FEATURES                                                                                                   L            B           L
                                                                                                                                                 DIM       MILLIMETERS
    Small Reverse Transfer Capacitance                                                                                                            A                _
                                                                                                                                                              2.93 + 0.20
      : Cre=0.65pF(Typ.).                                                                                                                         B        1.30+0.20/-0.15
                                                                                                                                                  C           1.30 MAX




                                                                                                                                           D
    Low Noise Figure :NF=2.2dB(Typ.) at f=100MHz.                                                             2                       3           D        0.45+0.15/-0.05




                                                                                               A

                                                                                                    G
                                                                                                                                                  E        2.40+0.30/-0.20




                                                                                                        H
                                                                                                              1                                   G              1.90
                                                                                                                                                  H              0.95
                                                                                                                                                  J        0.13+0.10/-0.05
                                                                                                                                                  K          0.00 ~ 0.10
                                                                                                                                                  L              0.55
                                                                                                                  P               P
  MAXIMUM RATING (Ta=25                 )                                                                                                         M           0.20 MIN
                                                                                                                                                  N        1.00+0.20/-0.10
              CHARACTERISTIC                 SYMBOL               RATING         UNIT                                                             P                7




                                                                                                         N
                                                                                                     C




                                                                                                                                           J
   Collector-Base Voltage                      VCBO                 40             V                                          M




                                                                                                                  K
   Collector-Emitter Voltage                   VCEO                 30             V
                                                                                                                 1. EMITTER
   Emitter-Base Voltage                        VEBO                  4             V                             2. BASE

                                                 IC                                                              3. COLLECTOR
   Collector Current                                                20            mA
   Emitter Current                               IE                 -20           mA
   Collector Power Dissipation                  PC *                350           mW
                                                                                                                              SOT-23
   Junction Temperature                          Tj                 150
   Storage Temperature Range                    Tstg              -55 150
  * PC : Package Mounted On 99.5% Alumina (10 8               0.6   )


                                                                                                         Marking
                                                                                                             h FE Rank                                       Lot No.


                                                                                                     Type Name
                                                                                                                              BF



  ELECTRICAL CHARACTERISTICS (Ta=25                           )
               CHARACTERISTIC                      SYMBOL                         TEST CONDITION              MIN.                        TYP.   MAX.              UNIT
   Collector Cut-off Current                           ICBO             VCB=40V, IE=0                                 -                    -       0.1                 A
   Emitter Cut-off Current                             IEBO             VEB=4V, IC=0                                  -                    -       0.1                 A
   DC Current Gain                                 hFE (Note)           VCE=5V, IC=1mA                            54                       -       198
   Reverse Transfer Capacitance                        Cre              VCE=6V, f=1MHz, IE=0                          -                    -       1.0               pF
   Transition Frequency                                 fT              VCE=6V, IC=1mA, f=200MHz                  260                      -           -            MHz
   Collector-Base Time Constant                    CC rbb'              VCE=6V, IE=-1mA, f=30MHz                      -                    -       30                pS
   Noise Figure                                        NF                                                             -                   2.2      4.0               dB
                                                                        VCE=6V, IE=-1mA, f=100MHz
   Power Gain                                          Gpe                                                        15                       -           -             dB
  Note) hFE Classification   F:54 80,       G:72 108,        H:97       146,   I:130   198




2003. 3. 25                      Revision No : 1                                                                                                                             1/3
                                                                                                                                      KTC9016S


                                                                             STATIC CHARACTERISTICS                                                                                                                                                          h FE - I C
                                                                                                                                                                                                           300
                                       20                                                                500                                                                                                                          COMMON EMITTER
                 COLLECTOR CURRENT




                                                                                                         450
                                                                                                          400                                                                                                                         VCE =6V




                                                                                                                                                                            DC CURRENT GAIN h FE
                                       16                                                                 350
                                                                                                           300                                                                                                                        Ta=25 C
                       I C (mA)




                                                                                                           250                                                                                             100
                                       12
                                                                            VCE =6V                         200
                                             8                                                                150
                                                                                                                 100                                                                                              50
                                             4                                                                   I B =50
