Image preview - the first page of the document
ktd1510


>> Download ktd1510 documenatation <<

Text preview - extract from the document
                                  SEMICONDUCTOR                                                                           KTD1510
                                          TECHNICAL DATA                                     TRIPLE DIFFUSED NPN TRANSISTOR


  HIGH POWER AMPLIFIER
                                                                                                         A                Q            B
  DARLINGTON TRANSISTOR.                                                                                                                   K




                                                                                                                      F
                                                                                                                          I
  FEATURES




                                                                                         E
    Complementary to KTB2510.




                                                                                                                              C
                                                                                                                                                DIM    MILLIMETERS
    Recommended for 60W Audio Amplifier Output Stage.                                                                                            A       15.9 MAX




                                                                                                                       J
                                                                                                                      H
                                                                                                                                                 B        4.8 MAX
                                                                                                                                                 C             _
                                                                                                                                                          20.0 + 0.3




                                                                                                                          G
                                                                                                                                                 D             _
                                                                                                                                                           2.0 + 0.3
                                                                                             D                                                   d      1.0+0.3/-0.25
                                                                                                                                                 E           2.0




                                                                                                                              L
                                                                                                                                                 F           1.0
  MAXIMUM RATING (Ta=25               )                                                      d
                                                                                                                                                 G        3.3 MAX
                                                                                                                                                 H           9.0
              CHARACTERISTIC                  SYMBOL          RATING     UNIT                                                                    I           4.5
                                                                                                     P       P                    T        M     J           2.0
   Collector-Base Voltage                        VCBO           160       V                                                                      K        1.8 MAX
                                                                                                                                                 L             _
                                                                                                                                                          20.5 + 0.5
   Collector-Emitter Voltage                     VCEO           150       V                                                                      M           2.8
                                                                                                                                                 P             _
                                                                                                                                                          5.45 + 0.2
   Emitter-Base Voltage                          VEBO            5        V                      1       2       3                               Q       3.2 + 0.2
                                                                                                                                                                _
                                                                                                                                                 T      0.6+0.3/-0.1
                                                                                                         1. BASE
   Collector Current                              IC            10        A
                                                                                                         2. COLLECTOR (HEAT SINK)
   Base Current                                   IB             1        A                              3. EMITTER

   Collector PowerDissipation (Tc=25      )       PC            100       W
   Junction Temperature                           Tj            150                                                           TO-3P(N)
   Storage Temperature Range                     Tstg         -55 150




                                                                                                 EQUIVALENT CIRCUIT
                                                                                                                                               COLLECTOR


                                                                                                             BASE




                                                                                                                                           70

                                                                                                                                                EMITTER


  ELECTRICAL CHARACTERISTICS (Ta=25                      )
               CHARACTERISTIC                     SYMBOL                TEST CONDITION                           MIN.             TYP.          MAX.          UNIT
   Collector Cut-off Current                           ICBO      VCB=160V, IE=0                                       -               -          100             A
   Emitter Cut-off Current                             IEBO      VEB=5V, IC=0                                         -               -          100             A
   Collector-Emitter Breakdown Voltage            V(BR)CEO       IC=30mA, IB=0                                       150              -           -              V
   DC Current Gain                                      hFE      VCE=4V, IC=7A                                       5000         12000         20000
   Collector-Emitter Saturation Voltage            VCE(sat)      IC=7A, IB=7mA                                        -               -          2.5             V
   Base-Emitter Saturation Voltage                 VBE(sat)      IC=7A, IB=7mA                                        -               -          3.0             V
   Transition Frequency                                 fT       VCE=12V, IC=2A                                       -               50          -           MHz
   Collector Output Capacitance                         Cob      VCB=10V, f=1MHz, IE=0                                -            230            -             pF




2008. 4. 18                    Revision No : 2                                                                                                                          1/3
                                KTD1510




2008. 4. 18   Revision No : 2             2/3
                                KTD1510




2008. 4. 18   Revision No : 2             3/3
