Image preview - the first page of the document
>> Download ktd1304 documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KTD1304
TECHNICAL DATA EPITAXIAL PLANAR NPN TRANSISTOR
AUDIO MUTING APPLICATION.
FEATURES E
High Emitter-Base Voltage : VEBO=12V(Min.). L B L
DIM MILLIMETERS
High Reverse hFE A _
2.93 + 0.20
: Reverse hFE=20(Min.) (VCE=2V, IC=4mA). B 1.30+0.20/-0.15
C 1.30 MAX
D
2
Low on Resistance : RON=0.6 (Max.) (IB=1mA). 3 D 0.40+0.15/-0.05
A
G
E 2.40+0.30/-0.20
H
1 G 1.90
H 0.95
J 0.13+0.10/-0.05
K 0.00 ~ 0.10
Q
L 0.55
P P
MAXIMUM RATING (Ta=25 ) M 0.20 MIN
N 1.00+0.20/-0.10
N
CHARACTERISTIC SYMBOL RATING UNIT
C
P 7
J
Q 0.1 MAX
Collector-Base Voltage VCBO 25 V
K
M
Collector-Emitter Voltage VCEO 20 V 1. EMITTER
2. BASE
Emitter-Base Voltage VEBO 12 V
3. COLLECTOR
Collector Current IC 300 mA
Base Current IB 30 mA
Collector Power Dissipation PC 200 mW SOT-23
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
Marking
Lot No.
Type Name
MAX
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector Cut-off Current ICBO VCB=25V, IE=0 - - 0.1 A
Emitter Cut-off Current IEBO VEB=12V, IC=0 - - 0.1 A
hFE1 (FOR) VCE=2V, IC=4mA 200 - 800
DC Current Gain
hFE2 (REV) VCE=2V, IC=4mA 20 - -
Collector-Emitter Saturation Voltage VCE(sat) IC=100mA, IB=10mA - - 0.25 V
Base-Emitter Saturation Voltage VBE(sat) IC=100mA, IB=10mA - - 1 V
Transition Frequency fT VCE=10V, IC=1mA - 60 - MHz
Collector Output Capacitance Cob VCB=10V, IE=0, f=1MHz - 10 - pF
On Resistance Ron f=1KHz, IB=1mA, Vin=0.3V - 0.6 -
2011. 6. 29 Revision No : 3 1/2
KTD1304
VCE(sat) - I C C ob - VCB
COLLECTOR OUTPUT CAPACITANCE
COLLECTOR-EMITTER SATURATION
1 24
I C /I B =25 I E =0
0.5 Ta=25 C
20 f=1MHz
VOLTAGE VCE(sat) (V)
0.3
16
C ob (pF)
Ta=25 C
0.1 12
0.05 8
Ta=75 C
0.03
Ta=-25 C
4
0.01 0
0.01 0.03 0.1 0.3 1 1 3 5 10 30 50 100
COLLECTOR CURRENT I C (A) COLLECTOR-BASE VOLTAGE VCB (V)
h FE - I C R on - I B
1.2k 1k 1k
VCE =2V
300 I B =1mA
ON RESISTANCE R on ()
1k
DC CURRENT GAIN h FE
f=1kHz
~ V=0.3V
100 VB VV VA
800
30 R ON =
VB
1000 ( )
VA VB
600 10
3
400
1
200
0.3
0 0.1
0.001 0.003 0.01 0.03 0.1 0.3 1 0.01 0.03 0.1 0.3 1 3 10
COLLECTOR CURRENT I C (A) BASE CURRENT IB (mA)
2011. 6. 29 Revision No : 3 2/2
