Image preview - the first page of the document
>> Download ktd2066 documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KTD2066
TECHNICAL DATA EPITAXIAL PLANAR NPN TRANSISTOR
HIGH CURRENT SWITCHING APPLICATION.
LAMP SOLENOID DRIVER APPLICATION.
A C
DIM MILLIMETERS
F
FEATURES S
A _
10.0 + 0.3
P
B _
15.0 + 0.3
High DC Current Gain E
C _
2.70 + 0.3
B
: hFE=500 1500(IC=1A). D 0.76+0.09/-0.05
G
E 3.2 + 0.2
_
Low Collector Saturation Voltage F _
3.0 + 0.3
G _
12.0 + 0.3
: VCE(sat)=0.35V(Max.) (IC=3A). H 0.5+0.1/-0.05
L L J _
13.6 + 0.5
K
R _
K 3.7 + 0.2
L 1.2+0.25/-0.1
M
M 1.5+0.25/-0.1
J
D D N _
2.54 + 0.1
P _
6.8 + 0.1
MAXIMUM RATING (Ta=25 ) _
4.5 + 0.2
Q
R _
2.6 + 0.2
CHARACTERISTIC SYMBOL RATING UNIT N N H S 0.5 Typ
Collector-Base Voltage VCBO 100 V
Collector-Emitter Voltage VCEO 80 V
1. BASE
Q
1 2 3
Emitter-Base Voltage VEBO 7 V 2. COLLECTOR
3. EMITTER
DC IC 5
Collector Current A
Pulse ICP 8
TO-220IS
Base Current IB 1 A
Collector Power Ta=25 2
PC W
Dissipation Tc=25 30 EQUIVALENT CIRCUIT
Junction Temperature Tj 150 COLLECTOR
Storage Temperature Range Tstg -55 150
BASE
EMITTER
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector Cut-off Current ICBO VCB=80V, IE=0 - - 10 A
Emitter Cut-off Current IEBO VEB=7V, IC=0 - - 10 A
Collector-Emitter Breakdown Voltage V(BR)CEO IC=50mA, IB=0 80 - - V
hFE(1) VCE=1V, IC=1A 500 - 1500
DC Current Gain
hFE(2) VCE=1V, IC=5A 150 - -
Collector-Emitter Saturation Voltage VCE(sat) IC=3A, IB=0.03A - - 0.35 V
Base-Emitter Saturation Voltage VBE(sat) IC=3A, IB=0.03A - - 1.2 V
Collector-Emitter Forward Voltage VECF IE=3A, IB=0 - - 2.5 V
Transition Frequency fT VCE=5V, IC=1A - 130 - MHz
Collector Output Capacitance Cob VCE=10V, IE=0, f=1MHz - 110 - pF
OUTPUT
Turn-on Time ton - 0.6 -
