ktk5164s


>> Download ktk5164s documenatation <<

Text preview - extract from the document
                                   SEMICONDUCTOR                                                                                  KTK5164S
                                                                                                                           N CHANNEL MOS FIELD
                                              TECHNICAL DATA                                                                EFFECT TRANSISTOR


  ULTRA-HIGH SPEED SWITCHING APPLICATIONS
  ANALOG SWITCH APPLICATIONS
                                                                                                                                       E
  FEATURES                                                                                                                    L        B           L
                                                                                                                                                               DIM    MILLIMETERS
    2.5 Gate Drive.                                                                                                                                             A            _
                                                                                                                                                                        2.93 + 0.20
    Low Threshold Voltage : Vth=0.5            1.5V.                                                                                                           B      1.30+0.20/-0.15
                                                                                                                                                               C         1.30 MAX




                                                                                                                                                       D
                                                                                                                              2
    High Speed.                                                                                                                                    3           D      0.45+0.15/-0.05




                                                                                                           A

                                                                                                                  G
                                                                                                                                                               E      2.40+0.30/-0.20
    Small Package.




                                                                                                                      H
                                                                                                                              1
                                                                                                                                                               G           1.90
    Enhancement-Mode.                                                                                                                                          H           0.95
                                                                                                                                                               J      0.13+0.10/-0.05
                                                                                                                                                                K         0.00 ~ 0.10
                                                                                                                                  P            P                L         0.55
                                                                                                                                                               M        0.20 MIN
  MAXIMUM RATINGS (Ta=25                  )                                                                                                                    N      1.00+0.20/-0.10




                                                                                                                       N
                                                                                                                  C




                                                                                                                                                       J
                                                                                                                                                               P           7
          CHARACTERISTIC                      SYMBOL             RATING          UNIT                                                      M




                                                                                                                                  K
    Drain-Source Voltage                       VDS                 60                 V
    Gate-Source Voltage                        VGSS                 20                V                                       1. SOURCE
                                                                                                                              2. GATE
    DC Drain Current                            ID                 200             mA                                         3. DRAIN

    Drain Power Dissipation                     PD                 200            mW
    Channel Temperature                         Tch                150
    Storage Temperature Range                   Tstg             -55 150                                                               SOT-23

  EQUIVALENT CIRCUIT
                                      D


                                                                                                                      Marking

          G
                                                                                                                                                                          Lot No.

                                                                                                                  Type Name
                                                                                                                                            KM
                                      S

         THIS TRANSISTOR IS ELECTROSTATIC SENSITIVE DEVICE.
         PLEASE HANDLE WITH CAUTION.

  ELECTRICAL CHARACTERISTICS (Ta=25 )
               CHARACTERISTIC                          SYMBOL                         TEST CONDITION                                  MIN.             TYP.     MAX.              UNIT
    Gate Leakage Current                                 IGSS           VGS=     16V, VDS=0V                                           -                   -          1                 A
    Drain-Source Breakdown Voltage                     V(BR)DSS         ID=100 A, VGS=0V                                               60                  -          -                 V
    Drain Cut-off Current                                IDSS           VDS=60V, VGS=0V                                                -                   -         1                  A
    Gate Threshold Voltage                               Vth            VDS=10V, ID=1mA                                               0.5                  -         1.5                V
    Forward Transfer Admittance                          |Yfs|          VDS=10V, ID=50mA                                              100                  -          -             mS
    Drain-Source ON Resistance                         RDS(ON)          ID=50mA, VGS=2.5V                                              -               1.5           2
    Input Capacitance                                    Ciss           VDS=10V, VGS=0V, f=1MHz                                        -                55           65             pF
    Reverse Transfer Capacitance                         Crss           VDS=10V, VGS=0V, f=1MHz                                        -                13           18             pF
    Output Capacitance                                   Coss           VDS=10V, VGS=0V, f=1MHz                                        -                40           50             pF
                                                          tr                                         I D =100mA
                              Rise Time                                  10V
                                                                                                                      V OUT            -                   8          -
                                                                                          VIN
                              Turn-on Time                ton             0                                                            -                14            -
                                                                                                           RL
                                                                                                50




    Switching Time                                                             10
