Image preview - the first page of the document
ku2303d


>> Download ku2303d documenatation <<

Text preview - extract from the document
                                   SEMICONDUCTOR                                                                          KU2303D
                                           TECHNICAL DATA                                                               N-Ch Trench MOSFET


  General Description

  This Trench MOSFET has better characteristics, such as fast switching
  time, low on resistance, low gate charge and excellent avalanche
                                                                                                            A                          K               DIM MILLIMETERS
  characteristics. It is mainly suitable for DC/DC Converter.                                               C                 D                L
                                                                                                                                                        A         _
                                                                                                                                                            6.60 + 0.20
                                                                                                                                                        B         _
                                                                                                                                                             6.10 + 0.20
                                                                                                                                                        C         _
                                                                                                                                                            5.34 + 0.30
                                                                                                                                                        D         _
                                                                                                                                                             0.70 + 0.20
                                                                                                                              B                         E         _
                                                                                                                                                            2.70 + 0.15
  FEATURES                                                                                                                                              F         _
                                                                                                                                                             2.30 + 0.10
                                                                                                                                                        G   0.96 MAX
    VDSS=30V, ID=68A.                                                                                                                                   H   0.90 MAX
                                                                                                H
                                                                                                                          J                             J         _
                                                                                                                                                             1.80 + 0.20
    Low Drain to Source On-state Resistance.                                                                                  E
                                                                                                                                                                  _
                                                                                                        G                                          N    K    2.30 + 0.10
     : RDS(ON)=6.8m (Max.) @ VGS=10V                                                                                                                    L         _
                                                                                                                                                            0.50 + 0.10
                                                                                                        F       F                              M        M         _
                                                                                                                                                             0.50 + 0.10
     : RDS(ON)=13.2m (Max.) @ VGS=4.5V                                                                                                                  N    0.70 MIN
                                                                                                                                                        O    0.1 MAX


                                                                                                    1       2       3              1. GATE
                                                                                                                                   2. DRAIN
                                                                                                                                   3. SOURCE
                                                                                                            O




  MAXIMUM RATING (Ta=25                   Unless otherwise Noted)
                   CHARACTERISTIC                         SYMBOL RATING                 UNIT                                      DPAK (1)
   Drain to Source Voltage                                      VDSS           30         V
   Gate to Source Voltage                                       VGSS
