Image preview - the first page of the document
>> Download kf3n80f documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KF3N80F
N CHANNEL MOS FIELD
TECHNICAL DATA EFFECT TRANSISTOR
General Description
A C
This planar stripe MOSFET has better characteristics, such as fast
F
switching time, low on resistance, low gate charge and excellent
O
avalanche characteristics. It is mainly suitable for active power factor E DIM MILLIMETERS
B
correction and switching mode power supplies. A _
10.16 + 0.2
G
B _
15.87 + 0.2
C _
2.54 + 0.2
FEATURES D _
0.8 + 0.1
E _
3.18 + 0.1
VDSS=800V, ID=3A
K
F _
3.3 + 0.1
Drain-Source ON Resistance : G _
12.57 + 0.2
L M
R H _
0.5 + 0.1
RDS(ON)(Max)=4.2 @VGS=10V
J
J _
13.0 + 0.5
Qg(typ.)=12nC K _
3.23 + 0.1
D
L 1.47 MAX
M 1.47 MAX
N N H
_
MAXIMUM RATING (Tc=25 ) N 2.54 + 0.2
O _
6.68 + 0.2
Q _
4.7 + 0.2
CHARACTERISTIC SYMBOL RATING UNIT 1. GATE
2. DRAIN R _
2.76 + 0.2
Q
1 2 3
Drain-Source Voltage VDSS 800 V 3. SOURCE
Gate-Source Voltage VGSS 30 V
@TC=25 3*
ID TO-220IS (1)
Drain Current @TC=100 1.9* A
Pulsed (Note1) IDP 6*
Single Pulsed Avalanche Energy EAS 175 mJ
(Note 2)
Repetitive Avalanche Energy EAR 4.4 mJ
(Note 1)
Peak Diode Recovery dv/dt
dv/dt 4.5 V/ns
(Note 3)
Drain Power Tc=25 32 W
PD
Dissipation Derate above 25 0.25 W/
Maximum Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
Thermal Characteristics
Thermal Resistance, Junction-to-Case RthJC 3.9 /W
Thermal Resistance,
RthJA 62.5 /W
Junction-to-Ambient
* : Drain current limited by maximum junction temperature.
PIN CONNECTION
D
G
S
2012. 7. 26 Revision No : 0 1/6
KF3N80F
ELECTRICAL CHARACTERISTICS (Tc=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Static
Drain-Source Breakdown Voltage BVDSS ID=250 A, VGS=0V 800 - - V
Breakdown Voltage Temperature Coefficient BVDSS/ Tj ID=250 A, Referenced to 25 - 0.8 - V/
Drain Cut-off Current IDSS VDS=800V, VGS=0V - - 10 A
Gate Threshold Voltage Vth VDS=VGS, ID=250 A 2.5 - 4.5 V
Gate Leakage Current IGSS VGS= 30V, VDS=0V - - 100 nA
Drain-Source ON Resistance RDS(ON) VGS=10V, ID=1.5A - 3.4 4.2
Dynamic
Total Gate Charge Qg - 12 -
VDS=480V, ID=3A
Gate-Source Charge Qgs - 6 - nC
VGS=10V (Note4,5)
Gate-Drain Charge Qgd - 2 -
Turn-on Delay time td(on) - 25 -
VDD=400V
Turn-on Rise time tr - 27 -
ID=3A ns
Turn-off Delay time td(off) - 60 -
RG=25 (Note4,5)
Turn-off Fall time tf - 30 -
Input Capacitance Ciss - 520 -
Output Capacitance Coss VDS=25V, VGS=0V, f=1.0MHz - 60 - pF
Reverse Transfer Capacitance Crss - 9 -
Source-Drain Diode Ratings
Continuous Source Current IS - - 3
VGS
