Image preview - the first page of the document
>> Download kf16n50f documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KF16N50P/F
N CHANNEL MOS FIELD
TECHNICAL DATA EFFECT TRANSISTOR
General Description
KF16N50P
This planar stripe MOSFET has better characteristics, such as fast A
O
C
switching time, low on resistance, low gate charge and excellent
F
avalanche characteristics. It is mainly suitable for active power factor
E G DIM MILLIMETERS
correction and switching mode power supplies. A _
9.9 + 0.2
B
B 15.95 MAX
Q C 1.3+0.1/-0.05
FEATURES I D _
0.8 + 0.1
E _
3.6 + 0.2
VDSS=500V, ID=16A
K P F _
2.8 + 0.1
Drain-Source ON Resistance : M G 3.7
L
H 0.5+0.1/-0.05
RDS(ON)(Max)=0.36 @VGS=10V J I 1.5
Qg(typ.)= 40.8nC D J _
13.08 + 0.3
N N H K 1.46
L _
1.4 + 0.1
MAXIMUM RATING (Tc=25 ) M _
1.27 + 0.1
N _
2.54 + 0.2
RATING O _
4.5 + 0.2
CHARACTERISTIC SYMBOL UNIT P _
2.4 + 0.2
1 2 3 1. GATE
KF16N50P KF16N50F 2. DRAIN Q _
9.2 + 0.2
3. SOURCE
Drain-Source Voltage VDSS 500 V
Gate-Source Voltage VGSS 30 V
TO-220AB
@TC=25 16 16*
ID
Drain Current @TC=100 9.7 9.7* A
IDP KF16N50F
Pulsed (Note1) 45 45*
A C
Single Pulsed Avalanche Energy EAS 870 mJ
(Note 2) F
O
Repetitive Avalanche Energy EAR 22.5 mJ
(Note 1) E DIM MILLIMETERS
B
A _
10.16 + 0.2
Peak Diode Recovery dv/dt
G
dv/dt 4.5 V/ns B _
15.87 + 0.2
(Note 3) _
C 2.54 + 0.2
Tc=25 225 51 W D _
0.8 + 0.1
Drain Power
PD E _
3.18 + 0.1
Dissipation
K
Derate above 25 1.78 0.41 W/ F _
3.3 + 0.1
G _
12.57 + 0.2
Maximum Junction Temperature Tj 150 L M
R H _
0.5 + 0.1
J
J _
13.0 + 0.5
Storage Temperature Range Tstg -55 150 _
K 3.23 + 0.1
D
L 1.47 MAX
Thermal Characteristics
M 1.47 MAX
N N H
Thermal Resistance, Junction-to-Case RthJC 0.58 2.43 /W N _
2.54 + 0.2
O _
6.68 + 0.2
Thermal Resistance, Q _
4.7 + 0.2
RthJA 62.5 62.5 /W 1. GATE
_
Junction-to-Ambient 2. DRAIN R 2.76 + 0.2
Q
1 2 3
3. SOURCE
* : Drain current limited by maximum junction temperature.
TO-220IS (1)
PIN CONNECTION
D
G
S
2008. 10. 2 Revision No : 1 1/7
KF16N50P/F
ELECTRICAL CHARACTERISTICS (Tc=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Static
Drain-Source Breakdown Voltage BVDSS ID=250 A, VGS=0V 500 - - V
Breakdown Voltage Temperature Coefficient BVDSS/ Tj ID=250 A, Referenced to 25 - 0.5 - V/
Drain Cut-off Current IDSS VDS=500V, VGS=0V - - 10 A
Gate Threshold Voltage Vth VDS=VGS, ID=250 A 2 - 4 V
Gate Leakage Current IGSS VGS= 30V, VDS=0V - - 100 nA
Drain-Source ON Resistance RDS(ON) VGS=10V, ID=8A - 0.3 0.36
Dynamic
Total Gate Charge Qg - 40.8 -
VDS=400V, ID=16A
Gate-Source Charge Qgs - 9 - nC
VGS=10V (Note4,5)
Gate-Drain Charge Qgd - 17 -
Turn-on Delay time td(on) - 30 -
VDD=250V
Turn-on Rise time tr - 21 -
ID=16A ns
Turn-off Delay time td(off) - 162 -
RG=25 (Note4,5)
Turn-off Fall time tf - 43 -
Input Capacitance Ciss - 1630 -
Output Capacitance Coss VDS=25V, VGS=0V, f=1.0MHz - 244 - pF
Reverse Transfer Capacitance Crss - 22 -
Source-Drain Diode Ratings
Continuous Source Current IS - - 16
VGS
