Image preview - the first page of the document
kf50n06p


>> Download kf50n06p documenatation <<

Text preview - extract from the document
                                  SEMICONDUCTOR                                                                       KF50N06P
                                                                                                              N CHANNEL MOS FIELD
                                         TECHNICAL DATA                                                        EFFECT TRANSISTOR

 General Description

    This planar stripe MOSFET has better characteristics, such as fast                                    A
                                                                                                                                     O
                                                                                                                                          C
 switching time, low on resistance, low gate charge and excellent
                                                                                                                          F
 avalanche characteristics. It is mainly suitable for active power factor
                                                                                          E                               G                   DIM MILLIMETERS
 correction , electronic lamp ballasts based on half bridge topology and                                                                       A        _
                                                                                                                                                    9.9 + 0.2
                                                                                                                              B
                                                                                                                                              B     15.95 MAX
 switching mode power supplies.                                                                                           Q                   C    1.3+0.1/-0.05
                                                                                          I                                                   D           _
                                                                                                                                                      0.8 + 0.1
                                                                                                                                              E            _
                                                                                                                                                       3.6 + 0.2
 FEATURES                                                                                 K                                                                _
                                                                                                                                      P        F      2.8 + 0.1
   VDSS = 60V, ID = 50A                                                                               M                                       G           3.7
                                                                                                                      L
                                                                                                                                              H    0.5+0.1/-0.05
   Drain-Source ON Resistance :                                                                                                J               I          1.5
   RDS(ON) =17m (Max.) @VGS = 10V                                                             D                                                J           _
                                                                                                                                                    13.08 + 0.3
                                                                                                      N       N                           H   K         1.46
   Qg(typ.) = 39.5nC
                                                                                                                                               L        _
                                                                                                                                                    1.4 + 0.1
                                                                                                                                              M          _
                                                                                                                                                    1.27 + 0.1
                                                                                                                                              N          _
                                                                                                                                                    2.54 + 0.2
                                                                                                                                              O         _
                                                                                                                                                    4.5 + 0.2
 MOSFET MAXIMUM RATING (Ta=25                      Unless otherwise noted)                        1       2       3           1. GATE          P         _
                                                                                                                                                    2.4 + 0.2
                                                                                                                              2. DRAIN        Q         _
                                                                                                                                                    9.2 + 0.2
             CHARACTERISTIC              SYMBOL         RATING             UNIT                                               3. SOURCE


  Drain-Source Voltage                     VDSS                 60                   V
  Gate-Source Voltage                      VGSS
