Image preview - the first page of the document
khb019n20f2


>> Download khb019n20f2 documenatation <<

Text preview - extract from the document
                                 SEMICONDUCTOR                                             KHB019N20P1/F1/F2
                                                                                                           N CHANNEL MOS FIELD
                                          TECHNICAL DATA                                                    EFFECT TRANSISTOR

  General Description                                                                                                              KHB019N20P1
                                                                                                           A
                                                                                                                                                           O
    This planar stripe MOSFET has better characteristics, such as fast                                                                                         C
                                                                                                                                       F
  switching time, low on resistance, low gate charge and excellent
                                                                                       E                                               G                           DIM MILLIMETERS
  avalanche characteristics. It is mainly suitable for DC/DC converters                                                                        B
                                                                                                                                                                    A        _
                                                                                                                                                                         9.9 + 0.2
                                                                                                                                                                   B         15.95 MAX
  and switching mode power supplies.                                                                                                   Q                           C        1.3+0.1/-0.05
                                                                                           I                                                                       D               _
                                                                                                                                                                               0.8 + 0.1
                                                                                                                                                                   E                _
                                                                                                                                                                                3.6 + 0.2
                                                                                           K                                                               P        F               _
                                                                                                                                                                               2.8 + 0.1
                                                                                                       M                                                           G               3.7
                                                                                                                               L
                                                                                                                                                                   H        0.5+0.1/-0.05
  FEATURES                                                                                                                                     J                    I              1.5
                                                                                               D                                                                    J               _
                                                                                                                                                                             13.08 + 0.3
    VDSS=200V, ID=19A                                                                                  N       N                                               H   K             1.46
                                                                                                                                                                                  _
                                                                                                                                                                              1.4 + 0.1
    Drain-Source ON Resistance : RDS(ON)=0.18       @VGS = 10V                                                                                                     M
                                                                                                                                                                    L
                                                                                                                                                                                   _
                                                                                                                                                                              1.27 + 0.1
    Qg(typ.)=35nC                                                                                                                                                  N               _
                                                                                                                                                                              2.54 + 0.2
                                                                                                                                                                                  _ 0.2
                                                                                                                                                                   O          4.5 +
                                                                                                   1       2       3                                                P              _
                                                                                                                                                                              2.4 + 0.2
                                                                                                                                           1. GATE
                                                                                                                                           2. DRAIN                Q              _
                                                                                                                                                                              9.2 + 0.2
                                                                                                                                           3. SOURCE


  MAXIMUM RATING (Tc=25 )
                                                                                                                                           TO-220AB
                                                               RATING
           CHARACTERISTIC                 SYMBOL                   KHB019N20F1 UNIT
                                                     KHB019N20P1                                                                   KHB019N20F1
                                                                   KHB019N20F2                             A                                                   C


   Drain-Source Voltage                     VDSS                 200             V




                                                                                                                                   F



                                                                                                                                                    O
   Gate-Source Voltage                      VGSS                   30            V     E                                                                                DIM     MILLIMETERS




                                                                                                                                           B
                                                                                                                                                                        A              _
                                                                                                                                                                                10.16 + 0.2




                                                                                                                               G
                     @TC=25                              19              19*                                                                                            B              _
                                                                                                                                                                                15.87 + 0.2
                                             ID                                                                                                                         C             _
                                                                                                                                                                                2.54 + 0.2
   Drain Current     @TC=100                            12.1            12.1*    A                                                                                      D            _
                                                                                                                                                                                 0.8 + 0.1
                                                                                                                                                                        E              _
                                                                                                                                                                                 3.18 + 0.1
                                                                                       K




                                                                                                                                                                                     _
                     Pulsed (Note1)          IDP         76              76*                                                                                            F        3.3 + 0.1
                                                                                                                                                                                      _ 0.2
                                                                                                                                                                        G       12.57 +
                                                                                           L                   M                                                                     _
   Single Pulsed Avalanche Energy           EAS
                                                                                                                                                               R        H        0.5 + 0.1
                                                                 250            mJ                                                         J                            J       13.0 MAX
   (Note 2)                                                                                                                                                             K            _
                                                                                                                                                                                3.23 + 0.1
                                                                                           D
                                                                                                                                                                                1.47 MAX
   Repetitive Avalanche Energy              EAR
                                                                                                                                                                        L
                                                                 14             mJ                                                                                      M       1.47 MAX
   (Note 1)                                                                                            N       N                                       H
                                                                                                                                                                        N             _
                                                                                                                                                                                2.54 + 0.2
                                                                                                                                                                        O            _
                                                                                                                                                                                6.68 + 0.2
   Peak Diode Recovery dv/dt
                                            dv/dt                4.5            V/ns                                                                                    Q             _
                                                                                                                                                                                  4.7 + 0.2
   (Note 3)                                                                                                                                                             R             _
                                                                                                                                                                                 2.76 + 0.2
                                                                                       Q




                                                                                                   1       2           3

   Drain Power       Tc=25                              140              50      W                                                                 1. GATE
                                             PD                                                                                                    2. DRAIN
                                                                                                                                                   3. SOURCE
   Dissipation       Derate above 25                    1.12             0.4    W/
   Maximum Junction Temperature              Tj                  150                                                           TO-220IS (1)
   Storage Temperature Range                Tstg               -55 150
                                                                                                                                   KHB019N20F2
   Thermal Characteristics
                                                                                                           A                                                   C
   Thermal Resistance, Junction-to-Case     RthJC       0.89             2.5     /W
                                                                                                                               F




                                                                                       S
                                            RthCS
                                                                                                                                                   P




   Thermal Resistance, Case-to-Sink                      0.5              -      /W        E                                                                       DIM        MILLIMETERS
                                                                                                                                                                    A              _
                                                                                                                                                                              10.0 + 0.3
                                                                                                                                       B




   Thermal Resistance, Junction-to-                                                                                                                                                _
                                            RthJA                                                                                                                   B
                                                                                                                               G




                                                                                                                                                                              15.0 + 0.3
                                                        62.5            62.5     /W
   Ambient                                                                                                                                                          C              _
                                                                                                                                                                              2.70 + 0.3
                                                                                                                                                                    D       0.76+0.09/-0.05
  * : Drain current limited by maximum junction temperature.                                                                                                        E            3.2 +0.2
                                                                                                                                                                                        _
                                                                                               L                           L                                        F                _
                                                                                                                                                                                 3.0 + 0.3
                                                                                       K




                                                                                                                                                               R
                                                                                                                                                                    G                _
                                                                                                                                                                                12.0 + 0.3
  PIN CONNECTION                                                                                                       M                                            H         0.5+0.1/-0.05
                                                                                                                                       J




                                                                                               D                           D                                        J                _
                                                                                                                                                                                13.6 + 0.5
                          D                                                                                                                                         K                _
                                                                                                                                                                                 3.7 + 0.2
                                                                                                                                                                    L         1.2+0.25/-0.1
                                                                                                                                                                    M         1.5+0.25/-0.1
                                                                                                       N       N                                               H    N               _
                                                                                                                                                                               2.54 +0.1
                                                                                                                                                                    P               _
                                                                                                                                                                                6.8 + 0.1
                                                                                                                                                                    Q               _
                                                                                                                                                                                4.5 + 0.2
                                                                                                                                                                    R               _
                                                                                                                                                                                2.6 + 0.2
                                                                                                                                                                                0.5 Typ
                                                                                                                               Q




                                                                                                   1       2       3                                                S
               G                                                                                                                                     1. GATE
                                                                                                                                                     2. DRAIN
                                                                                                                                                     3. SOURCE



                          S                                                                                                            TO-220IS



2010. 10. 27                    Revision No :1                                                                                                                                                1/7
                                                     KHB019N20P1/F1/F2

  ELECTRICAL CHARACTERISTICS (Tc=25 )
                 CHARACTERISTIC                         SYMBOL                     TEST CONDITION            MIN.   TYP.   MAX.   UNIT
    Static
    Drain-Source Breakdown Voltage                       BVDSS             ID=250 A, VGS=0V                  200     -       -     V
    Breakdown Voltage Temperature Coefficient           BVDSS/ Tj          ID=250 A, Referenced to 25         -     0.18     -    V/
    Drain Cut-off Current                                    IDSS          VDS=200V, VGS=0V,                  -      -      10     A
    Gate Threshold Voltage                                    Vth          VDS=VGS, ID=250 A                  2      -      4      V
    Gate Leakage Current                                     IGSS          VGS= 30V, VDS=0V                   -      -      100   nA
    Drain-Source ON Resistance                           RDS(ON)           VGS=10V, ID=9.5A                   -     0.14   0.18
    Dynamic
    Total Gate Charge                                         Qg                                              -      35     44
                                                                           VDS=160V, ID=19A
    Gate-Source Charge                                        Qgs                                             -     4.8      -     nC
                                                                           VGS=10V              (Note4,5)
    Gate-Drain Charge                                        Qgd                                              -      18      -
    Turn-on Delay time                                       td(on)                                           -      12     30
                                                                           VDD=100V
    Turn-on Rise time                                          tr                                             -      33     70
                                                                           RL=5                                                    ns
    Turn-off Delay time                                      td(off)                                          -     130    270
                                                                           RG=25                 (Note4,5)
    Turn-off Fall time                                         tf                                             -      75    160
    Input Capacitance                                        Ciss                                             -     900    1170
    Reverse Transfer Capacitance                             Crss          VDS=25V, VGS=0V, f=1.0MHz          -     213    277     pF
    Output Capacitance                                       Coss                                             -      80    104
    Source-Drain Diode Ratings
    Continuous Source Current                                  IS                                             -      -      19
                                                                           VGS
