Image preview - the first page of the document
khb019n20p1_f1_f2


>> Download khb019n20p1_f1_f2 documenatation <<

Text preview - extract from the document
                                 SEMICONDUCTOR                                                KHB019N20P1/F1/F2
                                                                                                              N CHANNEL MOS FIELD
                                              TECHNICAL DATA                                                   EFFECT TRANSISTOR

  General Description                                                                                                                 KHB019N20P1
                                                                                                              A
                                                                                                                                                              O
    This planar stripe MOSFET has better characteristics, such as fast                                                                                            C
                                                                                                                                          F
  switching time, low on resistance, low gate charge and excellent
                                                                                          E                                               G                           DIM MILLIMETERS
  avalanche characteristics. It is mainly suitable for DC/DC converters                                                                           B
                                                                                                                                                                       A        _
                                                                                                                                                                            9.9 + 0.2
                                                                                                                                                                      B         15.95 MAX
  and switching mode power supplies.                                                                                                      Q                           C        1.3+0.1/-0.05
                                                                                              I                                                                       D               _
                                                                                                                                                                                  0.8 + 0.1
                                                                                                                                                                      E                _
                                                                                                                                                                                   3.6 + 0.2
                                                                                              K                                                               P        F               _
                                                                                                                                                                                  2.8 + 0.1
                                                                                                          M                                                           G               3.7
                                                                                                                                  L
                                                                                                                                                                      H        0.5+0.1/-0.05
  FEATURES                                                                                                                                        J                    I              1.5
                                                                                                  D                                                                    J               _
                                                                                                                                                                                13.08 + 0.3
    VDSS=200V, ID=19A                                                                                     N       N                                               H   K             1.46
                                                                                                                                                                       L             _
                                                                                                                                                                                 1.4 + 0.1
    Drain-Source ON Resistance : RDS(ON)=0.18          @VGS = 10V                                                                                                     M               _
                                                                                                                                                                                 1.27 + 0.1
                                                                                                                                                                                      _
    Qg(typ.)=35nC                                                                                                                                                     N          2.54 + 0.2
                                                                                                                                                                                     _ 0.2
                                                                                                                                                                      O          4.5 +
                                                                                                      1       2       3                                                P              _
                                                                                                                                                                                 2.4 + 0.2
                                                                                                                                              1. GATE
                                                                                                                                              2. DRAIN                Q              _
                                                                                                                                                                                 9.2 + 0.2
                                                                                                                                              3. SOURCE


  MAXIMUM RATING (Tc=25                   )
                                                                                                                                              TO-220AB
                                                                  RATING
              CHARACTERISTIC                  SYMBOL                  KHB019N20F1 UNIT
                                                        KHB019N20P1                                                                   KHB019N20F1
                                                                      KHB019N20F2                             A                                                   C


   Drain-Source Voltage                        VDSS                 200             V




                                                                                                                                      F



                                                                                                                                                       O
   Gate-Source Voltage                         VGSS                   30            V     E                                                                                DIM     MILLIMETERS




                                                                                                                                              B
                                                                                                                                                                           A              _
                                                                                                                                                                                   10.16 + 0.2




                                                                                                                                  G
                     @TC=25                                 19              19*                                                                                            B              _
                                                                                                                                                                                   15.87 + 0.2
                                                ID                                                                                                                         C             _
                                                                                                                                                                                   2.54 + 0.2
                                                                                                                                                                                        _
                                                                                                                                                                                    0.8 + 0.1
   Drain Current     @TC=100                               12.1            12.1*    A                                                                                      D
                                                                                                                                                                           E              _
                                                                                                                                                                                    3.18 + 0.1
                                                                                          K




                                                                                                                                                                           F            _
                                                                                                                                                                                    3.3 + 0.1
                     Pulsed (Note1)             IDP         76              76*                                                                                                          _ 0.2
                                                                                                                                                                           G       12.57 +
                                                                                              L                   M                                                        H            _
                                                                                                                                                                                    0.5 + 0.1
   Single Pulsed Avalanche Energy              EAS
                                                                                                                                                                  R
                                                                    250            mJ                                                         J                            J       13.0 MAX
   (Note 2)                                                                                                                                                                K            _
                                                                                                                                                                                   3.23 + 0.1
                                                                                              D
                                                                                                                                                                           L       1.47 MAX
   Repetitive Avalanche Energy                 EAR                  14             mJ                     N       N
                                                                                                                                                                           M       1.47 MAX
   (Note 1)                                                                                                                                               H
                                                                                                                                                                           N             _
                                                                                                                                                                                   2.54 + 0.2
                                                                                                                                                                           O            _
                                                                                                                                                                                   6.68 + 0.2
   Peak Diode Recovery dv/dt
                                               dv/dt                4.5            V/ns                                                                                    Q             _
                                                                                                                                                                                     4.7 + 0.2
   (Note 3)                                                                                                                                                                R             _
                                                                                                                                                                                    2.76 + 0.2
                                                                                          Q




                                                                                                      1       2           3

   Drain Power       Tc=25                                 140              50      W                                                                 1. GATE
                                                                                                                                                      2. DRAIN
                                                PD                                                                                                    3. SOURCE
   Dissipation       Derate above 25                       1.12             0.4    W/
   Maximum Junction Temperature                 Tj                  150                                                           TO-220IS (1)
   Storage Temperature Range                   Tstg               -55 150
                                                                                                                                      KHB019N20F2
   Thermal Characteristics
                                                                                                              A                                                   C
   Thermal Resistance, Junction-to-Case        RthJC       0.89             2.5     /W
                                                                                                                                  F




                                                                                          S
                                                                                                                                                      P




   Thermal Resistance, Case-to-Sink            RthCS        0.5              -      /W        E                                                                       DIM        MILLIMETERS
                                                                                                                                                                       A              _
                                                                                                                                                                                 10.0 + 0.3
                                                                                                                                          B




   Thermal Resistance, Junction-to-                                                                                                                                    B              _
                                                                                                                                  G




                                                                                                                                                                                 15.0 + 0.3
                                               RthJA       62.5            62.5     /W                                                                                                _
   Ambient                                                                                                                                                             C         2.70 + 0.3
                                                                                                                                                                       D       0.76+0.09/-0.05
  * : Drain current limited by maximum junction temperature.                                                                                                           E            3.2 +0.2
                                                                                                                                                                                           _
                                                                                                  L                           L                                        F                _
                                                                                                                                                                                    3.0 + 0.3
                                                                                          K




                                                                                                                                                                  R
                                                                                                                                                                       G                _
                                                                                                                                                                                   12.0 + 0.3
  PIN CONNECTION                                                                                                          M                                            H         0.5+0.1/-0.05
                                                                                                                                          J




                                                                                                  D                           D                                        J                _
                                                                                                                                                                                   13.6 + 0.5
                          D                                                                                                                                            K                _
                                                                                                                                                                                    3.7 + 0.2
                                                                                                                                                                       L         1.2+0.25/-0.1
                                                                                                                                                                       M         1.5+0.25/-0.1
                                                                                                          N       N                                               H    N               _
                                                                                                                                                                                  2.54 +0.1
                                                                                                                                                                       P               _
                                                                                                                                                                                   6.8 + 0.1
                                                                                                                                                                       Q               _
                                                                                                                                                                                   4.5 + 0.2
                                                                                                                                                                       R               _
                                                                                                                                                                                   2.6 + 0.2
                                                                                                                                                                                   0.5 Typ
                                                                                                                                  Q




                                                                                                      1       2       3                                                S
                G                                                                                                                                       1. GATE
                                                                                                                                                        2. DRAIN
                                                                                                                                                        3. SOURCE



                          S                                                                                                               TO-220IS



2007. 5. 10                    Revision No : 0                                                                                                                                                   1/7
                                                    KHB019N20P1/F1/F2

 ELECTRICAL CHARACTERISTICS (Tc=25                             )
                CHARACTERISTIC                         SYMBOL                     TEST CONDITION            MIN.   TYP.   MAX.   UNIT
   Static
   Drain-Source Breakdown Voltage                       BVDSS             ID=250 A, VGS=0V                  200     -       -     V
   Breakdown Voltage Temperature Coefficient           BVDSS/ Tj          ID=250 A, Referenced to 25         -     0.18     -    V/
   Drain Cut-off Current                                    IDSS          VDS=200V, VGS=0V,                  -      -      10     A
   Gate Threshold Voltage                                    Vth          VDS=VGS, ID=250 A                  2      -      4      V
   Gate Leakage Current                                     IGSS          VGS= 30V, VDS=0V                   -      -      100   nA
   Drain-Source ON Resistance                           RDS(ON)           VGS=10V, ID=9.5A                   -     0.14   0.18
   Dynamic
   Total Gate Charge                                         Qg                                              -      35     44
                                                                          VDS=160V, ID=19A
   Gate-Source Charge                                        Qgs                                             -     4.8      -     nC
                                                                          VGS=10V              (Note4,5)
   Gate-Drain Charge                                        Qgd                                              -      18      -
   Turn-on Delay time                                       td(on)                                           -      12     30
                                                                          VDD=100V
   Turn-on Rise time                                          tr                                             -      33     70
                                                                          RL=5                                                    ns
   Turn-off Delay time                                      td(off)                                          -     130    270
                                                                          RG=25                 (Note4,5)
   Turn-off Fall time                                         tf                                             -      75    160
   Input Capacitance                                        Ciss                                             -     900    1170
   Reverse Transfer Capacitance                             Crss          VDS=25V, VGS=0V, f=1.0MHz          -     213    277     pF
   Output Capacitance                                       Coss                                             -      80    104
   Source-Drain Diode Ratings
   Continuous Source Current                                  IS                                             -      -      19
                                                                          VGS
