Image preview - the first page of the document
khb4d5n60p_f_f2


>> Download khb4d5n60p_f_f2 documenatation <<

Text preview - extract from the document
                                   SEMICONDUCTOR                                              KHB4D5N60P/F/F2
                                                                                                          N CHANNEL MOS FIELD
                                          TECHNICAL DATA                                                   EFFECT TRANSISTOR


  General Description                                                                                                             KHB4D5N60P
                                                                                                          A
                                                                                                                                                   O
    This planar stripe MOSFET has better characteristics, such as fast                                                                                 C
                                                                                                                                  F
  switching time, low on resistance, low gate charge and excellent
                                                                                          E                                       G                        DIM MILLIMETERS
  avalanche characteristics. It is mainly suitable for switching mode                                                                 B
                                                                                                                                                            A        _
                                                                                                                                                                 9.9 + 0.2
                                                                                                                                                           B         15.95 MAX
  power supplies.                                                                                                                 Q                        C        1.3+0.1/-0.05
                                                                                          I                                                                D               _
                                                                                                                                                                       0.8 + 0.1
                                                                                                                                                           E                _
                                                                                                                                                                        3.6 + 0.2
                                                                                          K                                                        P        F               _
                                                                                                                                                                       2.8 + 0.1
  FEATURES                                                                                            M                                                    G               3.7
                                                                                                                          L
                                                                                                                                                           H        0.5+0.1/-0.05
    VDSS(Min.)= 600V, ID= 4.5A                                                                                                         J                    I              1.5
                                                                                              D                                                             J               _
                                                                                                                                                                     13.08 + 0.3
    Drain-Source ON Resistance :                                                                      N       N                                        H   K              1.46
                                                                                                                                                                           _
    RDS(ON)=2.5      @VGS =10V                                                                                                                              L          1.4 + 0.1
                                                                                                                                                                            _
                                                                                                                                                           M           1.27 + 0.1
    Qg(typ.) =17nC                                                                                                                                         N                _
                                                                                                                                                                       2.54 + 0.2
                                                                                                                                                           O               _
                                                                                                                                                                       4.5 + 0.2
                                                                                                  1       2       3                                         P               _
                                                                                                                                                                       2.4 + 0.2
                                                                                                                                      1. GATE
                                                                                                                                      2. DRAIN             Q               _
                                                                                                                                                                       9.2 + 0.2
                                                                                                                                      3. SOURCE


  MAXIMUM RATING (Tc=25 )
                                                               RATING                                                                 TO-220AB

           CHARACTERISTIC                 SYMBOL                  KHB4D5N60F UNIT
                                                     KHB4D5N60P                                                                   KHB4D5N60F
                                                                  KHB4D5N60F2                                                                          C
                                                                                                          A

   Drain-Source Voltage                      VDSS                600            V




                                                                                                                              F



                                                                                                                                           O
   Gate-Source Voltage                       VGSS                 30            V     E                                                                         DIM     MILLIMETERS




                                                                                                                                  B
                                                                                                                                                                A               _
                                                                                                                                                                         10.16 + 0.2




                                                                                                                              G
                      @TC=25                             4.5           4.5*                                                                                     B               _
                                                                                                                                                                         15.87 + 0.2
                                              ID                                                                                                                C              _
                                                                                                                                                                         2.54 + 0.2
   Drain Current      @TC=100                            2.8           2.8*     A                                                                               D             _
                                                                                                                                                                          0.8 + 0.1
                                                                                                                                                                E               _
                                                                                                                                                                          3.18 + 0.1
                      Pulsed (Note1)         IDP         18              18*
                                                                                      K




                                                                                                                                                                F             _
                                                                                                                                                                          3.3 + 0.1
                                                                                                                                                                G              _
                                                                                                                                                                         12.57 + 0.2
                                                                                          L
   Single Pulsed Avalanche Energy                                                                             M
                                                                                                                                                       R        H             _
                                                                                                                                                                          0.5 + 0.1
                                             EAS                 260           mJ                                                 J                             J        13.0 MAX
   (Note 2)                                                                                                                                                     K             _
                                                                                                                                                                         3.23 + 0.1
                                                                                          D
   Repetitive Avalanche Energy                                                                                                                                  L        1.47 MAX
                                             EAR                10.6           mJ                                                                               M        1.47 MAX
   (Note 1)                                                                                           N       N                                H
                                                                                                                                                                N              _
                                                                                                                                                                         2.54 + 0.2
   Peak Diode Recovery dv/dt                                                                                                                                    O             _
                                                                                                                                                                         6.68 + 0.2
                                            dv/dt                4.5           V/ns                                                                             Q             _
                                                                                                                                                                          4.7 + 0.2
   (Note 3)                                                                                                                                                     R             _
                                                                                                                                                                         2.76 + 0.2
                                                                                      Q




                                                                                                  1       2       3

   Drain Power        Tc=25                             106              36     W                                                      1. GATE
                                              PD                                                                                       2. DRAIN
   Dissipation        Derate above25                    0.85           0.29    W/                                                      3. SOURCE


   Maximum Junction Temperature               Tj                 150                                                          TO-220IS (1)
   Storage Temperature Range                 Tstg              -55 150
                                                                                                                                  KHB4D5N60F2
   Thermal Characteristics
                                                                                                          A                                            C
   Thermal Resistance, Junction-to-Case      RthJC      1.18           3.47     /W
                                                                                                                              F




                                                                                      S
   Thermal Resistance, Case-to-Sink         RthCS        0.5              -     /W
                                                                                                                                           P




                                                                                          E                                                                DIM        MILLIMETERS
                                                                                                                                                                             _
   Thermal Resistance, Junction-to-                                                                                                                         A           10.0 + 0.3
                                                                                                                                  B




                                             RthJA      62.5           62.5     /W                                                                          B                _
                                                                                                                              G




                                                                                                                                                                        15.0 + 0.3
   Ambient                                                                                                                                                  C                _
                                                                                                                                                                        2.70 + 0.3
                                                                                                                                                            D         0.76+0.09/-0.05
  * : Drain current limited by maximum junction temperature.                                                                                                E            3.2 +0.2
                                                                                                                                                                                _
                                                                                              L                           L                                 F                _
                                                                                                                                                                         3.0 + 0.3
                                                                                      K




                                                                                                                                                       R
                                                                                                                                                            G                _
                                                                                                                                                                        12.0 + 0.3
  PIN CONNECTION                                                                                                      M                                     H         0.5+0.1/-0.05
                                                                                                                                  J




                                                                                              D                       D                                     J                _
                                                                                                                                                                        13.6 + 0.5
                          D                                                                                                                                 K                _
                                                                                                                                                                         3.7 + 0.2
                                                                                                                                                            L         1.2+0.25/-0.1
                                                                                                                                                            M         1.5+0.25/-0.1
                                                                                                      N       N                                        H    N                _
                                                                                                                                                                        2.54 +0.1
                                                                                                                                                            P                _
                                                                                                                                                                         6.8 + 0.1
                                                                                                                                                            Q                _
                                                                                                                                                                         4.5 + 0.2
                                                                                                                                                            R                _
                                                                                                                                                                         2.6 + 0.2
                                                                                                                                                                         0.5 Typ
                                                                                                                              Q




                                                                                                  1       2       3                                         S
                 G                                                                                                                         1. GATE
                                                                                                                                           2. DRAIN
                                                                                                                                           3. SOURCE



                           S                                                                                                      TO-220IS



2010. 10. 27                     Revision No : 1                                                                                                                                        1/7
                                                       KHB4D5N60P/F/F2

  ELECTRICAL CHARACTERISTICS (Tc=25 )

                CHARACTERISTIC                          SYMBOL                 TEST CONDITION           MIN.   TYP.   MAX.   UNIT

    Static
    Drain-Source Breakdown Voltage                           BVDSS     ID=250 A, VGS=0V                 600     -       -     V
    Breakdown Voltage Temperature Coefficient            BVDSS/ Tj     ID=250 A, Referenced to 25        -     0.6      -    V/
    Drain Cut-off Current                                    IDSS      VDS=600V, VGS=0V,                 -      -      10     A
    Gate Threshold Voltage                                    Vth      VDS=VGS, ID=250 A                 2      -      4      V
    Gate Leakage Current                                     IGSS      VGS= 30V, VDS=0V                  -      -      100   nA
    Drain-Source ON Resistance                           RDS(ON)       VGS=10V, ID=2.25A                 -     2.2     2.5
    Dynamic
    Total Gate Charge                                         Qg                                         -      17     21
                                                                       VDS=480V, ID=4.5A
    Gate-Source Charge                                        Qgs                                        -      3       -     nC
                                                                       VGS=10V              (Note4,5)
    Gate-Drain Charge                                         Qgd                                        -     7.3      -
    Turn-on Delay time                                       td(on)                                      -      15     35
                                                                       VDD=300V
    Turn-on Rise time                                          tr                                        -      35     80
                                                                       RL=67                                                  ns
    Turn-off Delay time                                      td(off)                                     -      70    150
                                                                       RG=25                (Note4,5)
    Turn-off Fall time                                         tf                                        -      80    170
    Input Capacitance                                         Ciss                                       -     655    850
    Output Capacitance                                        Coss     VDS=25V, VGS=0V, f=1.0MHz         -      66     86     pF
    Reverse Transfer Capacitance                              Crss                                       -      8      11
    Source-Drain Diode Ratings
    Continuous Source Current                                  IS                                        -      -      4.5
                                                                       VGS
