Image preview - the first page of the document
khb7d0n65p1_f1_f2


>> Download khb7d0n65p1_f1_f2 documenatation <<

Text preview - extract from the document
                                   SEMICONDUCTOR                                       KHB7D0N65P1/F1/F2
                                                                                                           N CHANNEL MOS FIELD
                                          TECHNICAL DATA                                                    EFFECT TRANSISTOR


  General Description
                                                                                                                                   KHB7D0N65P1
                                                                                                           A
                                                                                                                                                    O
     This planar stripe MOSFET has better characteristics, such as fast                                                                                 C
                                                                                                                                   F
  switching time, low on resistance, low gate charge and excellent
                                                                                           E                                       G                        DIM MILLIMETERS
                                                                                                                                                                      _
  avalanche characteristics. It is mainly suitable for active power factor                                                             B
                                                                                                                                                             A    9.9 + 0.2
                                                                                                                                                            B         15.95 MAX
  correction and switching mode power supplies.                                                                                    Q                        C        1.3+0.1/-0.05
                                                                                           I                                                                D               _
                                                                                                                                                                        0.8 + 0.1
                                                                                                                                                            E                _
                                                                                                                                                                         3.6 + 0.2
                                                                                           K                                                        P        F               _
                                                                                                                                                                        2.8 + 0.1
  FEATURES                                                                                             M                                                    G               3.7
                                                                                                                           L
                                                                                                                                                            H        0.5+0.1/-0.05
    VDSS=650V, ID=7A                                                                                                                    J                    I              1.5
                                                                                               D                                                             J               _
                                                                                                                                                                      13.08 + 0.3
    Drain-Source ON Resistance :                                                                       N       N                                        H   K              1.46
                                                                                                                                                             L              _
                                                                                                                                                                        1.4 + 0.1
    RDS(ON)=1.4    @VGS=10V                                                                                                                                 M                _
                                                                                                                                                                        1.27 + 0.1
                                                                                                                                                            N                _
                                                                                                                                                                        2.54 + 0.2
    Qg(typ.)= 32nC                                                                                                                                                          _ 0.2
                                                                                                                                                            O           4.5 +
                                                                                                   1       2       3                                         P               _
                                                                                                                                                                        2.4 + 0.2
                                                                                                                                       1. GATE
                                                                                                                                       2. DRAIN             Q               _
                                                                                                                                                                        9.2 + 0.2
  MAXIMUM RATING (Tc=25 )                                                                                                              3. SOURCE



                                                               RATING
                                                                                                                                       TO-220AB
           CHARACTERISTIC                 SYMBOL               KHB7D0N65F1 UNIT
                                                   KHB7D0N65P1
                                                               KHB7D0N65F2
                                                                                                                                   KHB7D0N65F1
                                           VDSS                                                            A                                            C
   Drain-Source Voltage                                          650             V




                                                                                                                               F
   Gate-Source Voltage                     VGSS                   30             V




                                                                                                                                            O
                                                                                       E                                                                         DIM     MILLIMETERS
                     @TC=25                              7               7*




                                                                                                                                   B
                                                                                                                                                                 A               _
                                                                                                                                                                          10.16 + 0.2




                                                                                                                               G
                                            ID                                                                                                                   B               _
                                                                                                                                                                          15.87 + 0.2
   Drain Current     @TC=100                            4.2              4.2*    A                                                                               C              _
                                                                                                                                                                          2.54 + 0.2
                                                                                                                                                                 D             _
                                                                                                                                                                           0.8 + 0.1
                                                                                                                                                                 E               _
                                                                                                                                                                           3.18 + 0.1
                     Pulsed (Note1)         IDP         28               28*                                                                                                   _
                                                                                       K




                                                                                                                                                                 F         3.3 + 0.1
                                                                                                                                                                 G              _ 0.2
                                                                                                                                                                          12.57 +
   Single Pulsed Avalanche Energy           EAS                                            L                   M                                                               _
                                                                 212            mJ                                                                      R        H         0.5 + 0.1
   (Note 2)                                                                                                                        J                             J        13.0 MAX
                                                                                                                                                                 K             _
                                                                                                                                                                          3.23 + 0.1
   Repetitive Avalanche Energy              EAR
                                                                                           D
                                                                 1.6            mJ                                                                               L        1.47 MAX
   (Note 1)                                                                                            N       N
                                                                                                                                                                 M        1.47 MAX
                                                                                                                                                H
                                                                                                                                                                 N              _
                                                                                                                                                                          2.54 + 0.2
   Peak Diode Recovery dv/dt                                                                                                                                     O             _
                                                                                                                                                                          6.68 + 0.2
                                           dv/dt                 4.5            V/ns
   (Note 3)                                                                                                                                                      Q             _
                                                                                                                                                                           4.7 + 0.2
                                                                                                                                                                 R             _
                                                                                                                                                                          2.76 + 0.2
                                                                                                   1       2       3
                                                                                       Q




   Drain Power       Tc=25                              160              52      W
                                                                                                                                        1. GATE
                                            PD                                                                                          2. DRAIN
   Dissipation       Derate above 25                   1.28              0.42   W/                                                      3. SOURCE


   Maximum Junction Temperature              Tj                  150                                                           TO-220IS (1)
   Storage Temperature Range                Tstg               -55 150
                                                                                                                                   KHB7D0N65F2
   Thermal Characteristics
                                                                                                           A                                            C
   Thermal Resistance, Junction-to-Case    RthJC       0.78              2.4     /W
                                                                                       S
                                                                                                                               F



                                                                                                                                            P




   Thermal Resistance, Case-to-Sink        RthCS        0.5               -      /W        E                                                                DIM        MILLIMETERS
                                                                                                                                                             A                _
                                                                                                                                                                         10.0 + 0.3
                                                                                                                                   B




   Thermal Resistance,                                                                                                                                       B                _
                                                                                                                                                                         15.0 + 0.3
                                                                                                                               G




                                           RthJA       62.5              62.5    /W                                                                          C                _
                                                                                                                                                                         2.70 + 0.3
   Junction-to-Ambient                                                                                                                                       D         0.76+0.09/-0.05
                                                                                                                                                             E                   _
                                                                                                                                                                          3.2 +0.2
  * : Drain current limited by maximum junction temperature.                                   L                           L
                                                                                                                                                        R    F                _
                                                                                                                                                                          3.0 + 0.3
                                                                                       K




                                                                                                                                                             G                _
                                                                                                                                                                         12.0 + 0.3
  PIN CONNECTION                                                                                                       M                                     H         0.5+0.1/-0.05
                                                                                                                                   J




                                                                                               D                       D                                     J                _
                                                                                                                                                                         13.6 + 0.5
                          D                                                                                                                                  K                _
                                                                                                                                                                          3.7 + 0.2
                                                                                                                                                             L         1.2+0.25/-0.1
                                                                                                                                                             M         1.5+0.25/-0.1
                                                                                                       N       N                                        H    N                _
                                                                                                                                                                         2.54 +0.1
                                                                                                                                                             P                _
                                                                                                                                                                          6.8 + 0.1
                                                                                                                                                             Q                _
                                                                                                                                                                          4.5 + 0.2
                                                                                                                                                             R                _
                                                                                                                                                                          2.6 + 0.2
                                                                                                   1       2       3                                         S            0.5 Typ
               G
                                                                                                                               Q




                                                                                                                                            1. GATE
                                                                                                                                            2. DRAIN
                                                                                                                                            3. SOURCE



                           S                                                                                                       TO-220IS



2010. 10. 27                   Revision No : 1                                                                                                                                           1/7
                                                        KHB7D0N65P1/F1/F2

  ELECTRICAL CHARACTERISTICS (Tc=25 )
                CHARACTERISTIC                           SYMBOL                     TEST CONDITION            MIN.   TYP.   MAX.   UNIT

    Static
    Drain-Source Breakdown Voltage                         BVDSS            ID=250 A, VGS=0V                  650     -       -     V
    Breakdown Voltage Temperature Coefficient            BVDSS/ Tj          ID=250 A, Referenced to 25         -     0.8      -    V/
    Drain Cut-off Current                                      IDSS         VDS=650V, VGS=0V,                  -      -      10     A
    Gate Threshold Voltage                                     Vth          VDS=VGS, ID=250 A                  2      -      4      V
    Gate Leakage Current                                       IGSS         VGS= 30V, VDS=0V                   -      -      100   nA
    Drain-Source ON Resistance                            RDS(ON)           VGS=10V, ID=3.75A                  -     1.2     1.4
    Dynamic
    Total Gate Charge                                           Qg                                             -      32     40
                                                                            VDS=520V, ID=7.0A
    Gate-Source Charge                                         Qgs                                             -     5.4      -     nC
                                                                            VGS=10V               (Note4,5)
    Gate-Drain Charge                                          Qgd                                             -     12.6     -
    Turn-on Delay time                                         td(on)                                          -      20     45
                                                                            VDD=325V
    Turn-on Rise time                                            tr                                            -      40     90
                                                                            RL=46                                                   ns
    Turn-off Delay time                                    td(off)                                             -     125    260
                                                                            RG=25                 (Note4,5)
    Turn-off Fall time                                           tf                                            -      80    170
    Input Capacitance                                          Ciss                                            -     1310   1700
    Output Capacitance                                         Coss         VDS=25V, VGS=0V, f=1.0MHz          -     113    147     pF
    Reverse Transfer Capacitance                               Crss                                            -     11.4   14.8
    Source-Drain Diode Ratings
    Continuous Source Current                                   IS                                             -      -      7
                                                                            VGS
