Image preview - the first page of the document
>> Download kma010p20q documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KMA010P20Q
TECHNICAL DATA P-Ch Trench MOSFET
General Description
It s mainly suitable for battery pack or power management
in cell phone, and PDA.
FEATURES H
T
VDSS=-20V, ID=-10A. D P G L
Drain-Source ON Resistance.
: RDS(ON)=14m (Max.) @ VGS=-4.5V, ID=-10A.
: RDS(ON)=24m (Max.) @ VGS=-2.5V, ID=-7.6A. A
DIM MILLIMETERS
A _
4.85 + 0.2
B1 _
3.94 + 0.2
8 5 B2 _
6.02 + 0.3
D _
0.4 + 0.1
B1 B2 G 0.15+0.1/-0.05
H _
1.63 + 0.2
1 4 L _
0.65 + 0.2
P 1.27
T 0.20+0.1/-0.05
MAXIMUM RATING (Ta=25 )
CHARACTERISTIC SYMBOL RATING UNIT
Drain-Source Voltage VDSS -20 V
FLP-8
Gate-Source Voltage VGSS 12 V
DC ID * 10
Drain Current A
Pulsed (Note1) IDP* 48
Source-Drain Diode Current IS * -2.3 A
Ta=25 1.6
Drain Power Dissipation PD * W
Ta=100 0.625
Maximum Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
Thermal Resistance, Junction to Ambient RthJA * 80 /W
* : Surface Mounted on 1 1 FR4 Board, t 5sec.
2007. 3. 22 Revision No : 1 1/5
KMA010P20Q
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Static
Drain-Source Breakdown Voltage BVDSS ID=-250 A, VGS=0V, -20 - - V
VGS=0V, VDS=-20V - - -1
Drain Cut-off Current IDSS A
VGS=0V, VDS=-16V, Tj=70 - - -5
Gate Threshold Voltage Vth VDS=VGS, ID=-250 A -0.6 - - V
Gate Leakage Current IGSS VGS= 12V, VDS=0V - - 100 nA
VGS=-4.5V, ID=-10A (Note 1) - 11 14
Drain-Source ON Resistance RDS(ON) m
VGS=-2.5V, ID=-7.6A (Note 1) - 18 24
ON State Drain Current ID(ON) VGS=-4.5V, VDS=-5V (Note 1) -48 - - A
Forward Transconductance gfs VDS=-5V, ID=-10A (Note 1) - 31 - S
Source-Drain Diode Forward Voltage VSD IS=-10A, VGS=0V (Note 1) - - -1.1 V
Dynamic (Note 2)
Total Gate Charge Qg - 36 -
VDS=-10V, RD=1.0
Gate-Source Charge Qgs - 5 - nC
VGS=-4.5V (Fig.1)
Gate-Drain Charge Qgd - 13 -
Turn-on Delay time td(on) - 10 -
Turn-on Rise time tr VDD=-10V, RD=1.0 , - 72 -
ns
Turn-off Delay time td(off) VGS=-4.5V, RG=6 (Fig.2) - 78 -
Turn-off Fall time tf - 108 -
Note 1) Pulse test : Pulse width 300 , Duty Cycle 2%.
Note 2) Guaranteed by design. Not subject to production testing.
2007. 3. 22 Revision No : 1 2/5
KMA010P20Q
2007. 3. 22 Revision No : 1 3/5
KMA010P20Q
2007. 3. 22 Revision No : 1 4/5
KMA010P20Q
2007. 3. 22 Revision No : 1 5/5
