Image preview - the first page of the document
kmb012n40da


>> Download kmb012n40da documenatation <<

Text preview - extract from the document
                                   SEMICONDUCTOR                                                          KMB012N40DA
                                           TECHNICAL DATA                                                     N-Ch Trench MOSFET


  General Description

  This Trench MOSFET has better characteristics, such as fast switching
  time, low on resistance, low gate charge and excellent avalanche
                                                                                                      A                        K            DIM MILLIMETERS
  characteristics. It is mainly suitable for Back-light Inverter and Power                            C                D            L
                                                                                                                                             A         _
                                                                                                                                                 6.60 + 0.20
                                                                                                                                                       _
  Supply.                                                                                                                                    B    6.10 + 0.20
                                                                                                                                             C         _
                                                                                                                                                 5.34 + 0.30
                                                                                                                                             D         _
                                                                                                                                                  0.70 + 0.20
                                                                                                                       B                     E         _
                                                                                                                                                 2.70 + 0.15
                                                                                                                                             F         _
                                                                                                                                                  2.30 + 0.10
                                                                                                                                             G   0.96 MAX
  FEATURES                                                                                                                                   H   0.90 MAX
                                                                                         H
                                                                                                                   J                         J         _
                                                                                                                                                  1.80 + 0.20
    VDSS=40V, ID=12A.                                                                                                  E
                                                                                                  G                                     N    K         _
                                                                                                                                                  2.30 + 0.10
    Low Drain-Source ON Resistance.                                                                                                          L         _
                                                                                                                                                 0.50 + 0.10
                                                                                                  F       F                          M       M         _
                                                                                                                                                  0.50 + 0.10
     : RDS(ON)=33m (Max.) @ VGS=10V                                                                                                          N    0.70 MIN
                                                                                                                                             O    0.1 MAX
     : RDS(ON)=47m (Max.) @ VGS=4.5V
    Super High Dense Cell Design.                                                             1       2       3              1. GATE
                                                                                                                             2. DRAIN
    High Power and Current Handling Capability.                                                                              3. SOURCE

                                                                                                      O




  MAXIMUM RATING (Ta=25                   Unless otherwise Noted)
                                                                                                                           DPAK (1)
                   CHARACTERISTIC                         SYMBOL         N-Ch     UNIT
   Drain-Source Voltage                                         VDSS      40       V
   Gate-Source Voltage                                          VGSS       20      V
                                DC@TC=25        (Note1)          ID       12                 Marking
   Drain Current                                                                   A
                                Pulsed         (Note2)          IDP       30                                                    Type Name

   Drain-Source Diode Forward Current                            IS       30       A
                                @TC=25          (Note1)                   45
   Drain Power Dissipation                                       PD                W                                KMB
                                @Ta=25          (Note2)                   3.1                                      012N40
                                                                                                                  DA                 Lot No
   Maximum Junction Temperature                                  Tj       150
   Storage Temperature Range                                    Tstg    -55 150
   Thermal Resistance, Junction to Case        (Note1)          RthJC     2.8      /W
   Thermal Resistance, Junction to Ambient (Note2)              RthJA     40       /W
  Note 1) RthJC means that the infinite heat sink is mounted.
  Note 2) Surface Mounted on 1 1 Pad of 2 oz copper.


  PIN CONNECTION (TOP VIEW)
                    D                                      2
                    2




                                                   1        3
              1             3
              G             S



2008. 9. 26                      Revision No : 0                                                                                                            1/5
                                                         KMB012N40DA

 ELECTRICAL CHARACTERISTICS (Ta=25 )
              CHARACTERISTIC                        SYMBOL              TEST CONDITION     MIN.   TYP.   MAX.   UNIT
   Static
   Drain-Source Breakdown Voltage                    BVDSS      VGS=0V, ID=250 A            40     -       -     V
   Drain Cut-off Current                              IDSS      VGS=0V, VDS=32V             -      -      1      A
   Gate Leakage Current                               IGSS      VGS=   20V, VDS=0V          -      -      100   nA
   Gate Threshold Voltage                             Vth       VDS=VGS, ID=250 A           1      -      3      V
                                                                VGS=10V, ID=12A             -      25     33
   Drain-Source ON Resistance                       RDS(ON)*                                                    m
                                                                VGS=4.5V, ID=6A             -      34     47
   Forward Transconductance                           gfs*      VDS=5V, ID=12A              -      3       -     S
   Dynamic
   Input Capacitance                                  Ciss                                  -     432      -
   Ouput Capacitance                                  Coss      VDS=20V, f=1MHz, VGS=0V     -     130      -     pF
   Reverse Transfer Capacitance                       Crss                                  -      50      -
                                  VGS=10V             Qg*                                   -     10.2     -
   Total Gate Charge
                                  VGS=4.5V            Qg*                                   -     5.5      -
                                                                VDS=24V, VGS=10V, ID=12A                         nC
   Gate-Source Charge                                Qgs*                                   -     2.2      -
   Gate-Drain Charge                                 Qgd*                                   -     2.4      -
   Turn-On Delay Time                                td(on)*                                -      5       -
   Turn-On Rise Time                                   tr*      VDD=20V, VGS=10V            -      6       -
                                                                                                                 ns
   Turn-Off Delay Time                               td(off)*   ID=12A, RG=3                -      15      -
   Turn-Off Fall Time                                  tf*                                  -      5       -
   Source-Drain Diode Ratings
   Source-Drain Forward Voltage                      VSDF*      VGS=0V, IS=1A               -     0.8     1.0    V
   Note>* Pulse Test : Pulse width <300   , Duty cycle < 2%




2008. 9. 26                       Revision No : 0                                                                      2/5
                                                                                                               KMB012N40DA


                                                                     Fig1. ID - VDS                                                                                                                  Fig2. RDS(ON)-ID




                                                                                                                            Drain Source On Resistance RDS(ON) (m)
                                        30                                                                                                                               75
                                                 VGS=10V         6.0V         5.0V
                                                                                                                                                                                    Ta=25 C
                                                                                                                   4.5V
                                        24                                                                                                                               60
        Drain Current ID (A)




                                        18                                                                                                                               45
                                                                                                                   4.0V                                                                                        VGS=4.5V

                                        12                                                                                                                               30
                                                                                                                                                                                                            VGS=10V
                                         6                                                                         3.5V                                                  15


                                         0                                                                                                                                0
                                             0           0.5              1               1.5              2          2.5                                                     0               6           12          18               24      30


                                                           Drain - Source Voltage VDS (V)                                                                                                           Drain - Current ID (A)



                                                                     Fig3. ID - VGS                                                                                                                 Fig4. RDS(on) - Tj
                                                                                                                                Drain-Source On-Resistance RDS(ON) (m)



                                        30                                                                                                                               75
                                                  VDS=VGS                                                                                                                         VGS=10V, ID=12A
                                        24                                                                                                                               60
       Drain Current ID (A)




                                        18                                                                                                                               45


                                        12                                                                                                                               30

                                                                              25 C
                                         6                                                                                                                               15
                                                                 Ta=125 C                        -55 C

                                         0                                                                                                                                 0
                                             1       1.5         2        2.5         3              3.5       4      4.5                                                   -75       -50     -25     0        25    50         75    100 125 150


                                                         Gate Source Volatage VGS (V)                                                                                                         Junction Temperature Tj ( C )




                                                                     Fig5. Vth - Tj                                                                                                                   Fig6. IS - VSDF

                                         5                                                                                                                               100
       Gate Threshold Voltage Vth (V)




                                                   VGS=VDS
                                                                                                                              Reverse Drain Current IS (A)




                                                   ID=250
