Image preview - the first page of the document
kmb4d0n30sa


>> Download kmb4d0n30sa documenatation <<

Text preview - extract from the document
                                  SEMICONDUCTOR                                                             KMB4D0N30SA
                                               TECHNICAL DATA                                                   N-Ch Trench MOSFET


  General Description

  This Trench MOSFET has better characteristics, such as fast switching
  time, low on resistance, low gate charge and excellent avalanche
                                                                                                                    E
  characteristics. It is mainly suitable for portable equipment.                                            L       B           L
                                                                                                                                        DIM   MILLIMETERS
                                                                                                                                         A            _
                                                                                                                                                 2.93 + 0.20
                                                                                                                                         B    1.30+0.20/-0.15
  FEATURES                                                                                                                               C       1.30 MAX




                                                                                                                                    D
                                                                                                            2                   3        D    0.40+0.15/-0.05
    VDSS=30V, ID=4A




                                                                                            A

                                                                                                G
                                                                                                                                         E    2.40+0.30/-0.20




                                                                                                        H
                                                                                                            1                            G          1.90
    Drain-Source ON Resistance                                                                                                           H          0.95
    RDS(ON)=47m (Max.) @ VGS=10V                                                                                                         J    0.13+0.10/-0.05
                                                                                                                                         K      0.00 ~ 0.10
    RDS(ON)=65m (Max.) @ VGS=4.5V                                                                               P           P
                                                                                                                                         L           0.55
                                                                                                                                         M       0.20 MIN
    Super High Dense Cell Design                                                                                                         N    1.00+0.20/-0.10




                                                                                                        N
                                                                                                    C
                                                                                                                                         P            7




                                                                                                                                    J
                                                                                                                        M




                                                                                                                K
                                                                                                                        SOT-23


  MAXIMUM RATING (Ta=25                    )
                   CHARACTERISTIC                            SYMBOL         N-Ch     UNIT
   Drain-Source Voltage                                         VDSS         30       V
   Gate-Source Voltage                                          VGSS          20      V
                                  DC@TA=25                                   4.0
                                                                I D*
   Drain Current                  DC@TA=70                                   3.5      A                             KNA
                                  Pulsed                        IDP*         20
   Drain-Source-Diode Forward Current                            IS         1.04      A
                                  TA=25                                     1.25
   Drain Power Dissipation                                      PD*                   W
                                  TA=70                                      0.8
   Maximum Junction Temperature                                  Tj          150
   Storage Temperature Range                                    Tstg       -55 150
   Thermal Resistance, Junction to Ambient                    RthJA*         100      /W
  Note > *Surface Mounted on 1       1 FR4 Board, t
