Image preview - the first page of the document
kmb6d0dn30qb


>> Download kmb6d0dn30qb documenatation <<

Text preview - extract from the document
                                  SEMICONDUCTOR                                        KMB6D0DN30QB
                                            TECHNICAL DATA                                 Dual N-Ch Trench MOSFET


  GENERAL DESCRIPTION

  This Trench MOSFET has better characteristics, such as fast switching
  time, low on resistance, low gate charge and excellent avalanche
                                                                                                             H
  characteristics. It is mainly suitable for portable equipment and DC-DC
                                                                                                                 T
  Converter Applications.                                                              D       P         G                 L
                                                                                                             U

  FEATURES
                                                                                           A
    VDSS=30V, ID=6A.
                                                                                                                     DIM       MILLIMETERS
    Drain-Source ON Resistance.                                                                                       A                  _
                                                                                                                                   4.85 + 0.2
                                                                                                                      B1                _
                                                                                                                                   3.94 + 0.2
     RDS(ON)=28m   (Max.) @VGS=10V                                                 8               5
                                                                                                                      B2                 _
                                                                                                                                   6.02 + 0.3
     RDS(ON)=42m   (Max.) @VGS=4.5V                                                                                   D                 _
                                                                                                                                    0.4 + 0.1
                                                                                                         B1 B2        G         0.15+0.1/-0.05
    Super High Dense Cell Design
                                                                                   1                                  H                  _
                                                                                                                                   1.63 + 0.2
                                                                                                   4
    High Power and Current Handing Capability                                                                         L                 _
                                                                                                                                   0.65 + 0.2
                                                                                                                      P               1.27
                                                                                                                      T         0.20+0.1/-0.05
                                                                                                                      U            0.1 MAX
  MAXIMUM RATING (Ta=25                  Unless otherwise noted)
              CHARACTERISTIC                       SYMBOL       PATING    UNIT
   Drain Source Voltage                                VDSS        30         V
                                                                                                             FLP-8
   Gate Source Voltage                                 VGSS         20        V
                                   DC                   ID *        6         A
   Drain Current
                                   Pulsed               IDP        30         A
   Drain Source Diode Forward Current                    IS        1.7        A
   Drain Power Dissipation         25                  PD *         2         W
   Maximum Junction Temperature                          Tj        150
                                                                                                       KMB6D0DN
   Storage Temperature Range                            Tstg    -50~150                                30QB

   Thermal Resistance, Junction to Ambient             RthJA*      62.5       /W
  Note> *Surface Mounted on FR4 Board, t 10sec.




   PIN CONNECTION (TOP VIEW)


       S1     1              8     D1              1                      8

       G1     2              7     D1              2                      7

       S2     3              6     D2              3                      6

       G2     4              5     D2              4                      5




2011. 8. 30                      Revision No : 0                                                                                                 1/5
                                                         KMB6D0DN30QB

  ELECTRICAL CHARACTERISTICS (Ta=25 ) UNLESS OTHERWISE NOTED
              CHARACTERISTIC                SYMBOL                   TEST CONDITION   MIN.   TYP.   MAX.   UNIT
   Static

   Drain-Source Breakdown Voltage             BVDSS         ID=250 A, VGS=0V           30     -       -     V

   Drain Cut-off Current                        IDSS        VDS=24V, VGS=0V            -      -      1         A

   Gate Leakage Current                         IGSS        VGS=   20V, VDS=0V         -      -      100   nA

   Gate Threshold Voltage                       Vth         VDS=VGS, ID=250 A         1.0    1.7     2.5    V

                                                            VGS=10V, ID=6A             -      24     28
   Drain-Source ON Resistance                RDS(ON)*                                                      m
                                                            VGS=4.5V, ID=5A            -      35     42

   On-State Drain Current                     ID(ON)*       VDS=5V, VGS=10V            20     -       -     A

   Forward Transconductance                     gfs*        VDS=5V, ID=6A              -      20      -     S

   Dynamic

   Input Capacitance                            Ciss                                   -     742      -

   Ouput Capacitance                            Coss        VDS=15V, f=1MHz, VGS=0V    -     126      -     pF

   Reverse Transfer Capacitance                 Crss                                   -      76      -

   Total Gate Charge                            Qg*                                    -     16.5     -

   Gate-Source Charge                          Qgs*         VDS=15V, VGS=10V, ID=6A    -     4.0      -     nC

   Gate-Drain Charge                           Qgd*                                    -     2.6      -

   Turn-On Delay Time                          td(on)*                                 -     7.4      -

   Turn-On Rise Time                            tr*         VDD=15V, VGS=10V           -     27.7     -
                                                                                                            ns
   Turn-Off Delay Time                        td(off)*      ID=6A, RG=3                -     12.2     -

   Turn-Off Fall Time                           tf*                                    -     7.6      -

   Source-Drain Diode Ratings

   Source-Drain Forward Voltage               VSDF*         IDR=1.7A, VGS=0V           -     0.75    1.2    V

   Note> * Pulse Test : Pulse width   300    , Duty cycle    2%




2011. 8. 30                       Revision No : 0                                                                  2/5
                                                                                                        KMB6D0DN30QB



                                                                         Fig1. ID - VDS                                                                                                              Fig2. RDS(on) - ID




                                                                                                                               Drain Source On Resistance RDS(ON) ()
                                             10                                                                                                                        0.16
                                                                                                                                                                                 Common Source
                                                                                                                                                                       0.14 Ta= 25 C
                                                                                                                                                                                 Pulse Test
                                              8
         Drain Current ID (A)




                                                                VGS=10, 9, 8, 7, 6, 5, 4V                                                                              0.12

                                              6                                                                                                                        0.1
                                                                                                         VGS=2.5V
                                                                                                                                                                       0.08
                                                                                                                                                                                                                              VGS=4.5
                                              4                                                                                                                        0.06

                                                                                                                                                                       0.04
                                              2
                                                                                                        VGS=1.5V                                                       0.02                                                             VGS=10.0

                                              0                                                                                                                         0
                                                  0      0.5          1.0        1.5             2.0     2.5        3.0                                                      0                   5                10               15          20

                                                               Drain - Source Voltage VDS (V)
                                                                                                                                                                                                     Drain Current ID (A)




                                                                        Fig3. ID - VGS                                                                                                                Fig4. RDS(ON) - Tj
                                                                                                                                                                       1.6
                                                                                                                             Normalized On Resistance RDS(ON)



                                              25
                                                                                                                                                                                 VGS = 10V
                                                                                                                                                                                 ID= 6A
                                                                     125 C                     25 C                                                                    1.4
       Drain Current ID (A)




                                              20

                                                                                               -55 C                                                                   1.2
                                              15
                                                                                                                                                                       1.0
                                              10
                                                                                                                                                                       0.8

                                              5
                                                                                                                                                                       0.6

                                              0                                                                                                                         0
                                                   0     1.0           2.0          3.0          4.0     5.0        6.0                                                     -75      -50      -25      0     25        50     75    100 125 150

                                                               Gate - Source Voltage VGS (V)                                                                                                  Junction Temperature Tj ( C )




                                                                            Fig5. Vth - Tj                                                                                                              Fig6. IS - VSDF

                                             1.6                                                                                                                        40
          Normalized Threshold Voltage Vth




                                                                                                        VDS = VGS
                                                                                                                          Reverse Drain Current IDR (A)




                                                                                                        ID = 250
