Image preview - the first page of the document
kmb8d2n60qa


>> Download kmb8d2n60qa documenatation <<

Text preview - extract from the document
                                     SEMICONDUCTOR                                               KMB8D2N60QA
                                              TECHNICAL DATA                                             N-Ch Trench MOSFET


 GENERAL DESCRIPTION

   This Trench MOSFET has better characteristics, such as fast switching time, low
 on resistance, low gate charge and excellent avalanche characteristiscs. It is mainly
 suitable for Back-light Inverter.                                                                               H
                                                                                                                     T
                                                                                             D       P       G                  L
 FEATURES
    VDSS=60V, ID=8.2A.
    Drain-Source ON Resistance.                                                                  A
                                                                                                                          DIM       MILLIMETERS
     RDS(ON)=22m (Max.) @ VGS=10V                                                                                          A               _
                                                                                                                                      4.85 + 0.2
                                                                                                                           B1              _
                                                                                                                                      3.94 + 0.2
     RDS(ON)=27m (Max.) @ VGS=4.5V                                                                                         B2              _
                                                                                         8               5                            6.02 + 0.3
    Super High Dense Cell Design                                                                                           D               _
                                                                                                                                       0.4 + 0.1
                                                                                                                 B1 B2     G        0.15+0.1/-0.05
                                                                                                                           H               _
                                                                                                                                      1.63 + 0.2
 MOSFET Maximum Ratings (Ta=25                     Unless otherwise noted)               1               4                 L               _
                                                                                                                                      0.65 + 0.2
                                                                                                                           P             1.27
                 CHARACTERISTIC                         SYMBOL PATING        UNIT                                          T        0.20+0.1/-0.05

   Drain Source Voltage                                  VDSS       60           V
   Gate Source Voltage                                   VGSS        20          V
                                     DC@TA=25                       8.2          A
                                                          I D*
   Drain Current                     DC@TA=70                       6.6          A
                                                                                                                  FLP-8

                                     Pulsed               IDP       40           A
   Drain Source Diode Forward Current                      IS       3.0          A
                                     TA=25                          3.0          W
   Drain Power Dissipation                                PD*
                                     TA=70                          2.0          W
                                                           Tj                                            KMB8D2N
   Maximum Junction Temperature                                    150
                                                                                                         60QA
   Storage Temperature Range                              Tstg    -55~150
   Thermal Resistance, Junction to Ambient               RthJA*     41           /W
  Note : *Surface Mounted on 1 1 FR4 Board




 PIN CONNECTION (TOP VIEW)



        S    1                       8   D          1                        8

                                                    2                        7
        S    2                       7   D
                                                    3                        6
        S    3                       6   D
                                                    4                        5
        G    4                       5   D




2007. 9. 3                       Revision No : 1                                                                                                     1/4
                                                           KMB8D2N60QA

 ELECTRICAL CHARACTERISTICS (Ta=25                              ) UNLESS OTHERWISE NOTED
             CHARACTERISTIC                   SYMBOL                     TEST CONDITION     MIN.   TYP.   MAX.   UNIT
   Static
   Drain-Source Breakdown Voltage               BVDSS           VGS=0V, IDS=250 A            60     -       -     V
                                                                VDS=48V, VGS=0V              -      -      1
   Drain Cut-off Current                         IDSS                                                                A
                                                                VDS=48V, VGS=0V, Tj=70       -      -      5
   Gate Leakage Current                          IGSS           VGS=   20V, VDS=0V           -      -      100   nA
   Gate Threshold Voltage                        Vth            VDS=VGS, ID=250 A           1.0     -      3.0    V
                                                                VGS=10V, ID=8.2A             -      16     22
   Drain-Source ON Resistance                  RDS(ON)*                                                          m
                                                                VGS=4.5V, ID=7.6A            -      20     27
   Forward Transconductance                      Gfs*           VDS=5V, ID=8.2A              -     2.4      -     S
   Dynamic
   Input Capaclitance                            Ciss                                        -     1920   2300
   Ouput Capacitance                             Coss           VDS=30V, VGS=0V, f=1MHz      -     155      -     pF
   Reverse Transfer Capacitance                  Crss                                        -     116      -
   Total Gate Charge (VGS=10V)                                                               -     47.6    58
                                                 Qg*
   Total Gate Charge (VGS=4.5V)                                                              -     24.2    30
                                                                VDS=30V, VGS=10V, ID=8.2A                         nC
   Gate-Source Charge                            Qgs*                                        -     6.0      -
   Gate-Drain Charge                             Qgd*                                        -     14.4     -
   Turn-On Delay Time                           td(on)*                                      -     8.2      -
   Turn-On Rise Time                              tr*           VDD=30V, VGS=10V             -     5.5      -
                                                                                                                  ns
   Turn-Off Delay Time                          td(off)*        RL=3.6 , RG=3                -     29.7     -
   Turn-Off Fall Time                             tf*                                        -     5.2      -
   Source-Drain Diode Ratings
   Source-Drain Forward Voltage                 VSDF*           VGS=0V, IDR=1.7A,            -     0.74    1.0    V
   Note
   1. Pulse Test : Pulse width    10   , Duty cycle        1%




2007. 9. 3                         Revision No : 1                                                                       2/4
                                                                                             KMB8D2N60QA


                                                                Fig1. ID - VDS                                                                             Fig2. RDS(ON) - ID

                                         40                                                                                             50        Common Source
                                                  VGS=8V, 10V                       Common Source




                                                                                                            On-Resistance RDS(ON) (m)
                                                                                    Ta=25 C                                                       Ta=25 C
                                                   VGS=6V                           Pulse Test                                                    Pulse Test
                                                                                                                                        40
       Drain Current ID (A)




                                         30
                                                   VGS=5.5V

                                                                                             VGS=4.0V                                   30
                                                                                                                                                                    VGS=4.5V
                                         20
                                                                                                                                        20

                                         10                                                  VGS=3.5V                                                                  VGS=10V
                                                                                                                                        10


                                          0                                                                                              0
                                           0           4          8            12        16         20                                       0        10          20          30     40      50


                                                      Drain - Source Voltage VDS (V)                                                                       Drain Current ID (A)




                                                                Fig3. ID - VGS                                                                             Fig4. RDS(ON) - Tj

                                         40                                                                                             60
                                                  Common Source
                                                                                                                                                 Common Source
                                                                                                            On-Resistance RDS(ON) (m)




                                                  VDS=5V
                                                                                                                                        50       VGS=10V
                                                  Pulse Test
       Drain Current ID (A)




                                                                                                                                                 Pulse Test
                                         30
                                                                                                                                        40

                                         20                                                                                             30

                                                                                                                                        20
                                         10
                                                                       150 C              25 C                                          10
                                                                                          -55 C
                                          0                                                                                              0
                                              0        1          2            3         4              5                                 -75 -50 -25      0      25     50   75 100 125 150 175


                                                       Gate Source Voltage VGS (V)                                                                     Junction Temperature Tj ( C )




                                                                Fig5. Vth - Tj                                                                                 Fig 6. IS - VSDF

                                         5                                                                                              40
        Gate Threshold Voltage Vth (V)




                                                                                                                                                 Common Source
                                                                                    Common Source
                                                                                                                                                 Ta=25 C
                                                                                    VGS=VDS
                                         4                                                                                                       Pulse Test
                                                                                                              Drain Current ID (A)




                                                                                    ID=250
