Image preview - the first page of the document
>> Download kn2907as_s documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KN2907S/AS
TECHNICAL DATA EPITAXIAL PLANAR PNP TRANSISTOR
GENERAL PURPOSE APPLICATION.
SWITCHING APPLICATION.
E
FEATURES L B L
DIM MILLIMETERS
Low Leakage Current A _
2.93 + 0.20
: ICEX=-50nA(Max.) ; VCE=-30V, VEB=-0.5V. B 1.30+0.20/-0.15
C 1.30 MAX
D
Low Saturation Voltage 2 3 D 0.45+0.15/-0.05
A
G
E 2.40+0.30/-0.20
: VCE(sat)=-0.4V(Max.) ; IC=150mA, IB=-15mA.
H
1 G 1.90
Complementary to the KN2222S/2222AS. H 0.95
J 0.13+0.10/-0.05
K 0.00 ~ 0.10
L 0.55
P P
M 0.20 MIN
N 1.00+0.20/-0.10
N
C
P 7
J
MAXIMUM RATING (Ta=25 )
M
K
RATING
CHARACTERISTIC SYMBOL UNIT
KN2907S KN2907AS 1. EMITTER
2. BASE
Collector-Base Voltage VCBO -60 V
3. COLLECTOR
Collector-Emitter Voltage VCEO -40 -60 V
Emitter-Base Voltage VEBO -5 V
Collector Current IC -600 mA
SOT-23
Collector Power Dissipation PC 150
mW
(Ta=25 ) PC * 350
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
Note : * Package Mounted On 99.5% Alumina 10 8 0.6 )
Marking
Type Name Lot No. Lot No.
ZDA Type Name
ZHA
MARK SPEC
TYPE MARK
KN2907S ZDA
KN2907AS ZHA
2002. 6. 25 Revision No : 3 1/3
KN2907S/AS
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector Cut-off Current ICEX VCE=-30V, VEB=-0.5V - - -50 nA
Collector Cut-off KN2907S - - -20
ICBO VCB=-50V, IE=0 nA
Current KN2907AS - - -10
Collector-Base Breakdown Voltage V(BR)CBO IC=-10 A, IE=0 -60 - - V
Collector-Emitter * KN2907S -40 - -
V(BR)CEO IC=-10mA, IB=0 V
Breakdown Voltage KN2907AS -60 - -
Emitter-Base Breakdown Voltage V(BR)EBO IE=-10 A, IC=0 -5 - - V
KN2907S 35 - -
hFE(1) IC=-0.1mA, VCE=-10V
KN2907AS 75 - -
KN2907S 50 - -
hFE(2) IC=-1.0mA, VCE=-10V
KN2907AS 100 - -
DC Current KN2907S 75 - -
hFE(3) IC=-10mA, VCE=-10V
Gain KN2907AS 100 - -
KN2907S
hFE(4) * IC=-150mA, VCE=-10V 100 - 300
KN2907AS
KN2907S 30 - -
hFE(5) * IC=-500mA, VCE=-10V
KN2907AS 50 - -
VCE(sat)1 IC=-150mA, IB=-15mA - - -0.4
Collector-Emitter Saturation Voltage * V
VCE(sat)2 IC=-500mA, IB=-50mA - - -1.6
VBE(sat)1 IC=-150mA, IB=-15mA - - -1.3
Base-Emitter Saturation Voltage * V
VBE(sat)2 IC=-500mA, IB=-50mA - - -2.6
VCE=-20V, IC=-50mA,
Transition Frequency fT 200 - - MHz
f=100MHz
Collector Output Capacitance Cob VCB=-10V, IE=0, f=1MHz - - 8 pF
* Pulse Test : Pulse Width 300 S, Duty Cycle 2%.
2002. 6. 25 Revision No : 3 2/3
KN2907S/AS
h FE - I C C ob - V CB
1k 12
VCE =-10V I E =0
f=1MHz
500 10
DC CURRENT GAIN h FE
CAPACITANCE Cob (pF)
300
8
100 6
50 4
30
2
10 0
-1 -3 -10 -30 -100 -300 -1k -1 -3 -10 -30 -100 -200
COLLECTOR CURRENT I C (mA) COLLECTOR-BASE VOLTAGE V CB (V)
V BE(sat) ,VCE(sat) - I C Pc - Ta
-10 500
COLLECTOR POWER DISSIPATION
I C /IB =10 1 MOUNTED ON 99.5%
-5
AIUMINA 10x8x0.6mm
SATURATION VOLTAGE
-3
400 2 Ta=25 C
V BE(sat) ,VCE(sat) (V)
1
V BE(sat)
-1
PC (mW)
300
-0.5
-0.3
200
2
-0.1
VCE(sat)
-0.05 100
-0.03
-0.01 0
-1 -3 -10 -30 -100 -300 -1k 0 25 50 75 100 125 150 175
COLLECTOR CURRENT I C (mA) AMBIENT TEMPERATURE Ta ( C)
2002. 6. 25 Revision No : 3 3/3
