Image preview - the first page of the document
>> Download kra116-122 documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KRA116~KRA122
TECHNICAL DATA EPITAXIAL PLANAR PNP TRANSISTOR
SWITCHING APPLICATION.
INTERFACE CIRCUIT AND DRIVER CIRCUIT APPLICATION
B C
FEATURES
With Built-in Bias Resistors.
A
Simplify Circuit Design.
Reduce a Quantity of Parts and Manufacturing Process. N DIM MILLIMETERS
E A 4.70 MAX
K
G B 4.80 MAX
D C 3.70 MAX
D 0.45
J
E 1.00
F 1.27
G 0.85
H 0.45
H J _
14.00 + 0.50
F F K 0.55 MAX
L 2.30
EQUIVALENT CIRCUIT BIAS RESISTOR VALUES M 0.45 MAX
TYPE NO. N 1.00
R1(k ) R2(k ) 1 2 3
C
L
M
OUT 1. EMITTER
KRA116 1 10
2. COLLECTOR
KRA117 2.2 2.2 3. BASE
R1
IN KRA118 2.2 10
R2
KRA119 4.7 10 TO-92
KRA120 10 4.7
COMMON(+)
KRA121 47 10
KRA122 100 100
MAXIMUM RATING (Ta=25 )
CHARACTERISTIC SYMBOL RATING UNIT
Output Voltage KRA116 122 VO -50 V
KRA116 -10, 5
KRA117 -12, 10
KRA118 -12, 5
Input Voltage KRA119 VI -20, 7 V
KRA120 -30, 10
KRA121 -40, 15
KRA122 -40, 10
Output Current IO -100 mA
Power Dissipation PD 625 mW
KRA116 122
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
2011. 6. 14 Revision No : 1 1/7
KRA116~KRA122
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Output Cut-off Current KRA116 122 IO(OFF) VO=-50V, VI=0 - - -500 nA
KRA116 VO=-5V, IO=-5mA 33 - -
KRA117 VO=-5V, IO=-20mA 20 - -
KRA118 VO=-5V, IO=-10mA 33 - -
DC Current Gain KRA119 GI VO=-5V, IO=-10mA 30 - -
KRA120 VO=-5V, IO=-10mA 24 - -
KRA121 VO=-5V, IO=-5mA 33 - -
KRA122 VO=-5V, IO=-5mA 62 - -
KRA116 IO=-10mA, II=-0.5mA - - -0.3
KRA117 IO=-10mA, II=-0.5mA - -0.1 -0.3
KRA118 IO=-10mA, II=-0.5mA - - -0.3
Output Voltage KRA119 VO(ON) IO=-10mA, II=-0.5mA - -0.1 -0.3 V
KRA120 IO=-10mA, II=-0.5mA - -0.1 -0.3
KRA121 IO=-10mA, II=-0.5mA - -0.1 -0.3
KRA122 IO=-5mA, II=-0.25mA - -0.1 -0.3
KRA116 VO=-0.3V, IO=-20mA - -0.98 -3
KRA117 VO=-0.3V, IO=-20mA - -1.83 -3
KRA118 VO=-0.3V, IO=-20mA - -1.22 -3
Input Voltage (ON) KRA119 VI(ON) VO=-0.3V, IO=-20mA - -1.76 -2.5 V
KRA120 VO=-0.3V, IO=-2mA - -2 -3
KRA121 VO=-0.3V, IO=-2mA - -3.9 -5
KRA122 VO=-0.3V, IO=-1mA - -1.64 -3
KRA116 -0.3 -0.63 -
KRA117 -0.5 -1.15 -
KRA118 -0.3 -0.67 -
Input Voltage (OFF) KRA119 VI(OFF) VCC=-5V, IO=-100 A -0.3 -0.82 - V
KRA120 -0.8 -1.68 -
KRA121 -1 -3.09 -
KRA122 -0.5 -1.17 -
Transition Frequency KRA116 122 f T* VO=-10V, IO=-5mA - 250 - MHz
KRA116 - - -7.2
KRA117 - - -3.8
KRA118 - - -3.8
Input Current KRA119 II VI=-5V - - -1.8 mA
KRA120 - - -0.88
KRA121 - - -0.16
KRA122 - - -0.15
KRA116 0.7 1 1.3
KRA117 1.54 2.2 2.86
KRA118 1.54 2.2 2.86
Input Resistor KRA119 R1 - 3.29 4.7 6.11 k
KRA120 7 10 13
KRA121 32.9 47 61.1
KRA122 70 100 130
Note : * Characteristic of Transistor Only.
2011. 6. 14 Revision No : 1 2/7
KRA116~KRA122
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
KRA116M - 0.01 -
KRA117M - 0.03 -
KRA118M - 0.02 -
Rise
KRA119M tr - 0.05 -
Time
KRA120M - 0.12 -
KRA121M - 0.30 -
KRA122M - 0.35 -
KRA116M - 3 -
KRA117M - 2 -
KRA118M VO=-5V - 3 -
Switching Storage
KRA119M tstg VIN=-5V - 3 - S
Time Time
KRA120M RL=1k - 2 -
KRA121M - 2 -
KRA122M - 2 -
KRA116M - 0.1 -
KRA117M - 0.19 -
KRA118M - 0.1 -
Fall
KRA119M tf - 0.36 -
Time
KRA120M - 0.35 -
KRA121M - 0.5 -
KRA122M - 0.7 -
2011. 6. 14 Revision No : 1 3/7
KRA116~KRA122
I O - V I(ON) I O - V I(ON)
KRA116 KRA117
-100 -100
-50 -50
OUTPUT CURRENT IO (mA)
OUTPUT CURRENT I O (mA)
-30
-30
-10
-10 -5
Ta=25 C
-5 -3 Ta=-25 C
Ta=25 C
-3 Ta=-25 C Ta=100 C
Ta=100 C -1
-0.5
-1 -0.3
-0.5 VO =-0.2V VO =-0.2V
-0.3 -0.1
-0.1 -0.3 -1 -3 -10 -0.1 -0.3 -1 -3 -10
INPUT ON VOLTAGE V I(ON) (V) INPUT ON VOLTAGE V I(ON) (V)
I O - V I(OFF) I O - V I(OFF)
KRA116 KRA117
-3k -3k
