Image preview - the first page of the document
>> Download kra116_119m documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KRA116M~KRA122M
TECHNICAL DATA EPITAXIAL PLANAR PNP TRANSISTOR
SWITCHING APPLICATION.
INTERFACE CIRCUIT AND DRIVER CIRCUIT APPLICATION
B
FEATURES
A
With Built-in Bias Resistors.
Simplify Circuit Design. O DIM MILLIMETERS
F
A 3.20 MAX
H
Reduce a Quantity of Parts and Manufacturing Process. M B 4.30 MAX
C 0.55 MAX
G
D _
2.40 + 0.15
E 1.27
F 2.30
C _
G 14.00+ 0.50
H 0.60 MAX
J 1.05
E E
K 1.45
L 25
J
M 0.80
D
K
1 2 3 N N 0.55 MAX
EQUIVALENT CIRCUIT BIAS RESISTOR VALUES O 0.75
L
TYPE NO. R1(k ) R2(k )
1. COMMON (EMITTER)
OUT
KRA116M 1 10 2. OUT (COLLECTOR)
3. IN (BASE)
KRA117M 2.2 2.2
R1
IN KRA118M 2.2 10
R2
KRA119M 4.7 10 TO-92M
KRA120M 10 4.7
COMMON(+)
KRA121M 47 10
KRA122M 100 100
MAXIMUM RATING (Ta=25 )
CHARACTERISTIC SYMBOL RATING UNIT
Output Voltage KRA116M 122M VO -50 V
KRA116M -10, 5
KRA117M -12, 10
KRA118M -12, 5
Input Voltage KRA119M VI -20, 7 V
KRA120M -30, 10
KRA121M -40, 15
KRA122M -40, 10
Output Current IO -100 mA
Power Dissipation PD 400 mW
KRA116M 122M
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
2008. 11. 20 Revision No : 4 1/7
KRA116M~KRA122M
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Output Cut-off Current KRA116M 122M IO(OFF) VO=-50V, VI=0 - - -500 nA
KRA116M VO=-5V, IO=-5mA 33 - -
KRA117M VO=-5V, IO=-20mA 20 - -
KRA118M VO=-5V, IO=-10mA 33 - -
DC Current Gain KRA119M GI VO=-5V, IO=-10mA 30 - -
KRA120M VO=-5V, IO=-10mA 24 - -
KRA121M VO=-5V, IO=-5mA 33 - -
KRA122M VO=-5V, IO=-5mA 62 - -
KRA116M IO=-10mA, II=-0.5mA - - -0.3
KRA117M IO=-10mA, II=-0.5mA - -0.1 -0.3
KRA118M IO=-10mA, II=-0.5mA - - -0.3
Output Voltage KRA119M VO(ON) IO=-10mA, II=-0.5mA - -0.1 -0.3 V
KRA120M IO=-10mA, II=-0.5mA - -0.1 -0.3
KRA121M IO=-10mA, II=-0.5mA - -0.1 -0.3
KRA122M IO=-5mA, II=-0.25mA - -0.1 -0.3
KRA116M VO=-0.3V, IO=-20mA - -0.98 -3
KRA117M VO=-0.3V, IO=-20mA - -1.83 -3
KRA118M VO=-0.3V, IO=-20mA - -1.22 -3
Input Voltage (ON) KRA119M VI(ON) VO=-0.3V, IO=-20mA - -1.76 -2.5 V
KRA120M VO=-0.3V, IO=-2mA - -2 -3
KRA121M VO=-0.3V, IO=-2mA - -3.9 -5
KRA122M VO=-0.3V, IO=-1mA - -1.64 -3
KRA116M -0.3 -0.63 -
KRA117M -0.5 -1.15 -
KRA118M -0.3 -0.67 -
Input Voltage (OFF) KRA119M VI(OFF) VCC=-5V, IO=-100 A -0.3 -0.82 - V
KRA120M -0.8 -1.68 -
KRA121M -1 -3.09 -
KRA122M -0.5 -1.17 -
Transition Frequency KRA116M 122M f T* VO=-10V, IO=-5mA - 250 - MHz
KRA116M - - -7.2
Input Current II VI=-5V mA
KRA117M - - -3.8
- -
KRA116M 0.7 1 1.3
KRA117M 1.54 2.2 2.86
KRA118M 1.54 2.2 2.86
Input Resistor KRA119M R1 - 3.29 4.7 6.11 k
KRA120M 7 10 13
KRA121M 32.9 47 61.1
KRA122M 70 100 130
KRA116M 8 10 12
KRA117M 0.8 1.0 1.2
KRA118M 3.6 4.5 5.5
Resistor Ratio KRA119M R2/R1 - 1.7 2.1 2.6
KRA120M 0.37 0.47 0.57
KRA121M 0.17 0.21 0.26
KRA122M 0.8 1.0 1.2
Note : * Characteristic of Transistor Only.
2008. 11. 20 Revision No : 4 2/7
KRA116M~KRA122M
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
KRA116M - 0.01 -
KRA117M - 0.03 -
KRA118M - 0.02 -
Rise
KRA119M tr - 0.05 -
Time
KRA120M - 0.12 -
KRA121M - 0.30 -
KRA122M - 0.35 -
KRA116M - 3 -
KRA117M - 2 -
KRA118M VO=-5V - 3 -
Switching Storage
KRA119M tstg VIN=-5V - 3 - S
Time Time
KRA120M RL=1k - 2 -
KRA121M - 2 -
KRA122M - 2 -
KRA116M - 0.1 -
KRA117M - 0.19 -
KRA118M - 0.1 -
Fall
KRA119M tf - 0.36 -
Time
KRA120M - 0.35 -
KRA121M - 0.5 -
KRA122M - 0.7 -
2008. 11. 20 Revision No : 4 3/7
KRA116M~KRA122M
I O - V I(ON) I O - V I(ON)
KRA116M KRA117M
-100 -100
-50
OUTPUT CURRENT IO (mA)
OUTPUT CURRENT I O (mA)
-50
-30
-30
-10
-10 -5
Ta=25 C
-5 -3 Ta=-25 C
Ta=25 C
-3 Ta=-25 C Ta=100 C
Ta=100 C -1
-0.5
-1 -0.3
-0.5 VO =-0.2V VO =-0.2V
-0.3 -0.1
-0.1 -0.3 -1 -3 -10 -0.1 -0.3 -1 -3 -10
INPUT ON VOLTAGE V I(ON) (V) INPUT ON VOLTAGE V I(ON) (V)
I O - V I(OFF) I O - V I(OFF)
KRA116M KRA117M
-3k -3k
