Image preview - the first page of the document
>> Download kra116_22s documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KRA221S~KRA226S
TECHNICAL DATA EPITAXIAL PLANAR PNP TRANSISTOR
HIGH CURRENT SWITCHING APPLICATION.
INTERFACE CIRCUIT AND DRIVER CIRCUIT APPLICATION.
E
L B L
FEATURES DIM MILLIMETERS
A _
2.93 + 0.20
With Built-in Bias Resistors. B 1.30+0.20/-0.15
C 1.30 MAX
Simplify Circuit Design.
D
2 3 D 0.40+0.15/-0.05
A
G
Reduce a Quantity of Parts and Manufacturing Process. E 2.40+0.30/-0.20
H
1 G 1.90
High Output Current :-800mA. H 0.95
J 0.13+0.10/-0.05
K 0.00 ~ 0.10
Q
L 0.55
P P
M 0.20 MIN
N 1.00+0.20/-0.10
N
C
P 7
J
Q 0.1 MAX
EQUIVALENT CIRCUIT BIAS RESISTOR VALUES
K
M
OUT TYPE NO. R1(k ) R2(k )
1. COMMON (EMITTER)
KRA221S 1 1
2. IN (BASE)
R1 KRA222S 2.2 2.2 3. OUT (COLLECTOR)
IN
R2 KRA223S 4.7 4.7
KRA224S 10 10
KRA225S 1 10 SOT-23
COMMON(+)
KRA226S 2.2 10
MAXIMUM RATING (Ta=25 )
CHARACTERISTIC SYMBOL RATING UNIT
Output Voltage KRA221S 226S VO -50 V
KRA221S -10, 10
KRA222S -12, 10
KRA223S -20, 10
Input Voltage VI V
KRA224S -30, 10
KRA225S -10, 5
KRA226S -12, 6
Output Current IO -800 mA
Power Dissipation PD 200 mW
KRA221S 226S
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
MARK SPEC Marking
TYPE KRA221S KRA222S KRA223S KRA224S KRA225S KRA226S Lot No.
MARK PQ PR PS PT PU PV Type Name
2008. 10. 30 Revision No : 3 1/5
KRA221S~KRA226S
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Output Cut-off Current KRA221S 226S IO(OFF) VO=-30V, VI=0 - - -10 A
KRA221S 33 - -
KRA222S 39 - -
KRA223S 47 - -
DC Current Gain GI VO=-5V, IO=-50mA
KRA224S 56 - -
KRA225S 56 - -
KRA226S 56 - -
Output Voltage KRA221S 226S VO(ON) IO=-50mA, II=-2.5mA - -0.1 -0.3 V
KRA221S - - -3.0
KRA222S - - -3.0
KRA223S - - -3.0
Input Voltage (ON) VI(ON) VO=-0.3V, IO=-20mA V
KRA224S - - -3.0
KRA225S - - -3.0
KRA226S - - -2.0
KRA221S 224S -0.5 - -
Input Voltage (OFF) VI(OFF) VO=-5V, IO=-0.1mA V
KRA225S 226S -0.3 - -
VO=-10V, IO=-5mA,
Transition Frequency KRA221S 226S fT* - 200 - MHz
f=100MHz
KRA221S - - -7.2
KRA222S - - -3.8
KRA223S - - -1.8
Input Current II VI=-5V mA
KRA224S - - -0.88
KRA225S - - -7.2
KRA226S - - -3.6
KRA221S 0.1 1 1.3
KRA222S 1.54 2.2 2.86
KRA223S 3.29 4.7 6.11
Input Resistor R1 - k
KRA224S 7 10 13
KRA225S 0.7 1 1.3
KRA226S 1.54 2.2 2.86
KRA241S~244S 0.8 1.0 1.2
Resistor Ratio KRA245S R2/R1 - 0.08 0.1 0.12
KRA246S 3.6 4.5 5.5
2008. 10. 30 Revision No : 3 2/5
KRA221S~KRA226S
I O - VI(ON) I O - VI(ON)
KRA221S KRA222S
-500 -500
-300 VO =-0.3V -300 VO =-0.3V
OUTPUT CURRENT I O (mA)
OUTPUT CURRENT I O (mA)
-100 -100
-50 -50
-30 -30
Ta=100 C
Ta=100 C
-10 -10
-5 -5
-3 -3
Ta=25 C Ta=25 C
Ta=-25 C Ta=-25 C
-1 -1
-0.5 -0.5
-0.3 -0.3
-0.1 -0.3 -1 -3 -10 -30 -100 -300 -1k -0.1 -0.3 -1 -3 -10 -30 -100 -300 -1k
INPUT ON VOLTAGE V I(ON) (V) INPUT ON VOLTAGE V I(ON) (V)
I O - V I(OFF) I O - V I(OFF)
KRA221S KRA222S
-5k -5k
-3k VO =-5V -3k V O =-5V
