Image preview - the first page of the document
>> Download kra301v documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KRA301V~KRA306V
TECHNICAL DATA EPITAXIAL PLANAR PNP TRANSISTOR
SWITCHING APPLICATION.
INTERFACE CIRCUIT AND DRIVER CIRCUIT APPLICATION.
E
FEATURES B
With Built-in Bias Resistors.
Simplify Circuit Design.
2 DIM MILLIMETERS
Reduce a Quantity of Parts and Manufacturing Process. A _
1.2 +0.05
D
G
A
B _
0.8 +0.05
High Packing Density.
H
1 3 _
C 0.5 + 0.05
K
D _
0.3 + 0.05
E _
1.2 + 0.05
G _
0.8 + 0.05
P P H 0.40
_
EQUIVALENT CIRCUIT BIAS RESISTOR VALUES J 0.12 + 0.05
_
K 0.2 + 0.05
TYPE NO. P 5
OUT R1(k ) R2(k )
C
J
KRA301V 4.7 4.7
R1
IN KRA302V 10 10
1. COMMON (EMITTER)
R2 KRA303V 22 22 2. IN (BASE)
3. OUT (COLLECTOR)
KRA304V 47 47
COMMON(+) KRA305V 2.2 47
KRA306V 4.7 47 VSM
MAXIMUM RATING (Ta=25 )
CHARACTERISTIC SYMBOL RATING UNIT
Output Voltage KRA301V 306V VO -50 V
KRA301V -20, 10
KRA302V -30, 10
KRA303V -40, 10
Input Voltage VI V
KRA304V -40, 10
KRA305V -12, 5
KRA306V -20, 5
Output Current IO -100 mA
Power Dissipation PD 100 mW
KRA301V 306V
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
MARK SPEC Marking
Type Name
TYPE KRA301V KRA302V KRA303V KRA304V KRA305V KRA306V
MARK PA PB PC PD PE PF
2008. 11. 20 Revision No : 2 1/6
KRA301V~KRA306V
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Output Cut-off Current KRA301V 306V IO(OFF) VO=-50V, VI=0 - - -500 nA
KRA301V 30 55 -
KRA302V 50 80 -
KRA303V 70 120 -
DC Current Gain GI VO=-5V, IO=-10mA
KRA304V 80 200 -
KRA305V 80 200 -
KRA306V 80 200 -
Output Voltage KRA301V 306V VO(ON) IO=-10mA, II=-0.5mA - -0.1 -0.3 V
KRA301V - -1.5 -2.0
KRA302V - -1.8 -2.4
KRA303V - -2.1 -3.0
Input Voltage (ON) VI(ON) VO=-0.2V, IO=-5mA V
KRA304V - -2.8 -5.0
KRA305V - -0.8 -1.1
KRA306V - -0.9 -1.3
KRA301V 304V -1.0 -1.2 -
Input Voltage (OFF) VI(OFF) VO=-5V, IO=-0.1mA V
KRA305V 306V -0.5 -0.65 -
Transition Frequency KRA301V 306V fT * VO=-10V, IO=-5mA - 200 - MHz
KRA301V - - -1.8
KRA302V - - -0.88
KRA303V - - -0.36
Input Current II VI=-5V mA
KRA304V - - -0.18
KRA305V - - -3.6
KRA306V - - -1.8
KRA301V 3.29 4.7 6.11
KRA302V 7 10 13
KRA303V 15.4 22 28.6
Input Resistor R1 - k
KRA304V 32.9 47 61.1
KRA305V 1.54 2.2 2.86
KRA306V 3.29 4.7 6.11
KRA301V 304V 0.8 1.0 1.2
Resistor Ratio KRA305V R2/R1 - 17 21 26
KRA306V 8 10 12
Note : * Characteristic of Transistor Only.
2008. 11. 20 Revision No : 2 2/6
KRA301V~KRA306V
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
KRA301V - 0.07 -
KRA302V - 0.06 -
KRA303V - 0.2 -
Rise Time tr
KRA304V - 0.24 -
KRA305V - 0.02 -
KRA306V - 0.07 -
KRA301V - 1.1 -
KRA302V - 1.1 -
VO=-5V
Switching KRA303V - 1.1 -
Storage Time tstg VIN=-5V S
Time KRA304V - 1.1 -
RL=1k
KRA305V - 1.1 -
KRA306V - 1.1 -
KRA301V - 0.15 -
KRA302V - 0.24 -
KRA303V - 0.38 -
Fall Time tf
KRA304V - 0.63 -
KRA305V - 0.1 -
KRA306V - 0.2 -
2008. 11. 20 Revision No : 2 3/6
KRA301V~KRA306V
I O - V I(ON) I O - V I(ON)
KRA301V KRA302V
-100 -25
-100
VO =-0.2V VO =-0.2V
25 -25
OUTPUT CURRENT I O (mA)
OUTPUT CURRENT IO (mA)
-50 -50 25
100
-30 -30 100
-10 -10
-5 -5
Ta=100 C
Ta=100 C
-3 -3
Ta=25 C Ta=25 C
Ta=-25 C Ta=-25 C
-1 -1
-0.5 -0.5
-0.3 -0.3
-0.1 -0.3 -1 -3 -10 -30 -100 -0.1 -0.3 -1 -3 -10 -30 -100
INPUT ON VOLTAGE V I(ON) (V) INPUT ON VOLTAGE V I(ON) (V)
I O - V I(ON) I O - V I(ON)
KRA303V KRA304V
-100 -100
VO =-0.2V VO =-0.2V
OUTPUT CURRENT IO (mA)
OUTPUT CURRENT I O (mA)
-50 -50
-30 -30
-10 -10
-5 -5
Ta=100 C
Ta=25 C Ta=100 C
-3 -3
Ta=-25 C
Ta=25 C
Ta=-25 C
-1 -1
-0.5 -0.5
-0.3 -0.3
-0.1 -0.3 -1 -3 -10 -30 -100 -0.1 -0.3 -1 -3 -10 -30 -100
INPUT ON VOLTAGE V I(ON) (V) INPUT ON VOLTAGE V I(ON) (V)
I O - VI(ON) I O - V I(ON)
KRA305V KRA306V
-100 -100
VO =-0.2V VO =-0.2V
OUTPUT CURRENT I O (mA)
OUTPUT CURRENT IO (mA)
-50 -50
-30 -30
-10 -10
-5 -5
Ta=100 C
Ta=100 C
-3 Ta=25 C -3 Ta=25 C
Ta=-25 C Ta=-25 C
-1 -1
-0.5 -0.5
-0.3 -0.3
-0.1 -0.3 -1 -3 -10 -30 -100 -0.1 -0.3 -1 -3 -10 -30 -100
INPUT ON VOLTAGE V I(ON) (V) INPUT ON VOLTAGE V I(ON) (V)
2008. 11. 20 Revision No : 2 4/6
KRA301V~KRA306V
I O - V I(OFF) I O - V I(OFF)
KRA301V KRA302V
-10k -10k
VO =-5V VO =-5V
-5k
