Image preview - the first page of the document
>> Download krc101-106 documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KRC101~KRC106
TECHNICAL DATA EPITAXIAL PLANAR NPN TRANSISTOR
SWITCHING APPLICATION.
INTERFACE CIRCUIT AND DRIVER CIRCUIT APPLICATION.
B C
FEATURES
With Built-in Bias Resistors.
A
Simplify Circuit Design.
Reduce a Quantity of Parts and Manufacturing Process.
N DIM MILLIMETERS
E A 4.70 MAX
K
G B 4.80 MAX
D C 3.70 MAX
D 0.45
J
E 1.00
F 1.27
G 0.85
H 0.45
H J _
14.00 + 0.50
EQUIVALENT CIRCUIT BIAS RESISTOR VALUES
F F K 0.55 MAX
TYPE NO. L 2.30
R1(k ) R2(k )
M 0.45 MAX
OUT
N 1.00
KRC101 4.7 4.7 1 2 3
C
L
M
1. EMITTER
R1 KRC102 10 10
IN 2. COLLECTOR
KRC103 22 22 3. BASE
R2
KRC104 47 47
KRC105 2.2 47 TO-92
COMMON
KRC106 4.7 47
MAXIMUM RATING (Ta=25 )
CHARACTERISTIC SYMBOL RATING UNIT
Output Voltage KRC101 106 VO 50 V
KRC101 20, -10
KRC102 30, -10
KRC103 40, -10
Input Voltage VI V
KRC104 40, -10
KRC105 12, -5
KRC106 20, -5
Output Current IO 100 mA
Power Dissipation PD 625 mW
KRC101 106
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
2011. 7. 26 Revision No : 2 1/6
KRC101~KRC106
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Output Cut-off Current KRC101 106 IO(OFF) VO=50V, VI=0 - - 500 nA
KRC101 30 55 -
KRC102 50 80 -
KRC103 70 120 -
DC Current Gain GI VO=5V, IO=10mA
KRC104 80 200 -
KRC105 80 200 -
KRC106 80 200 -
Output Voltage KRC101 106 VO(ON) IO=10mA, II=0.5mA - 0.1 0.3 V
KRC101 - 1.5 2.0
KRC102 - 1.8 2.4
KRC103 - 2.1 3.0
Input Voltage (ON) VI(ON) VO=0.2V, IO=5mA V
KRC104 - 2.8 5.0
KRC105 - 0.8 1.1
KRC106 - 0.9 1.3
KRC101 104 1.0 1.2 -
Input Votlage (OFF) VI(OFF) VO=5V, IO=0.1mA V
KRC105 106 0.5 0.65 -
Transition Frequency KRC101 106 fT * VO=10V, IO=5mA - 200 - MHz
KRC101 - - 1.8
KRC102 - - 0.88
KRC103 - - 0.36
Input Current II VI=5V mA
KRC104 - - 0.18
KRC105 - - 3.6
KRC106 - - 1.8
KRC101 3.29 4.7 6.11
KRC102 7 10 13
KRC103 15.4 22 28.6
Input Resistor R1 - k
KRC104 32.9 47 61.1
KRC105 1.54 2.2 2.86
KRC106 3.29 4.7 6.11
KRC101 3.29 4.7 6.11
KRC102 7 10 13
KRC103 15.4 22 28.6
Input Resistor R2 - k
KRC104 32.9 47 61.1
KRC105 32.9 47 61.1
KRC106 32.9 47 61.1
Note : * Characteristic of Transistor Only.
2011. 7. 26 Revision No : 2 2/6
KRC101~KRC106
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
KRC101 - 0.03 -
KRC102 - 0.05 -
KRC103 - 0.12 -
Rise Time tr
KRC104 - 0.22 -
KRC105 - 0.01 -
KRC106 - 0.03 -
KRC101 - 2.0 -
KRC102 - 2.0 -
VO=5V
Switching KRC103 - 2.0 -
Storage Time tstg VIN=5V S
Time KRC104 - 2.0 -
RL=1k
KRC105 - 2.0 -
KRC106 - 2.0 -
KRC101 - 0.12 -
KRC102 - 0.36 -
KRC103 - 0.35 -
Fall Time tf
KRC104 - 0.6 -
KRC105 - 0.1 -
KRC106 - 0.19 -
2011. 7. 26 Revision No : 2 3/6
KRC101~KRC106
I O - VI(ON) I O - VI(ON)
KRC101 KRC102
100 100
VO =0.2V 25 VO =0.2V
-25
OUTPUT CURRENT I O (mA)
50 50
OUTPUT CURRENT I O (mA)
30 100 30
10 10
Ta=25 C
5 5
00 C
C
Ta=-25 C Ta=25 C
3 3
00
Ta=1
Ta=-25 C
Ta=1
1 1
0.5 0.5
0.3 0.3
0.1 0.3 1 3 10 30 100 0.1 0.3 1 3 10 30 100
INPUT ON VOLTAGE V I(ON) (V) INPUT ON VOLTAGE V I(ON) (V)
I O - VI(ON) I O - VI(ON)
KRC103 KRC104
100 100
VO =0.2V VO =0.2V
OUTPUT CURRENT I O (mA)
50 50
OUTPUT CURRENT I O (mA)
30 30
10 10
0 C
5 5
C
Ta=25 C Ta=25 C
00
10
3 Ta=-25 C 3 =1
Ta=
Ta=-25 C
Ta
1 1
0.5 0.5
0.3 0.3
0.1 0.3 1 3 10 30 100 0.1 0.3 1 3 10 30 100
INPUT ON VOLTAGE V I(ON) (V) INPUT ON VOLTAGE V I(ON) (V)
I O - V I(ON) I O - VI(ON)
KRC105 KRC106
100 100
VO =0.2V VO =0.2V
OUTPUT CURRENT I O (mA)
50 50
OUTPUT CURRENT I O (mA)
30 30
10 10
00 C
00 C
5 5
Ta=25 C Ta=25 C
3 3
Ta=1
Ta=1
Ta=-25 C Ta=-25 C
1 1
0.5 0.5
0.3 0.3
0.1 0.3 1 3 10 30 100 0.1 0.3 1 3 10 30 100
INPUT ON VOLTAGE V I(ON) (V) INPUT ON VOLTAGE V I(ON) (V)
2011. 7. 26 Revision No : 2 4/6
KRC101~KRC106
I O - VI(OFF) I O - V I(OFF)
KRC101 KRC102
10k 10k
VO =5V VO =5V
5k 5k
