Image preview - the first page of the document
>> Download krc101_6s documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KRC101S~KRC106S
TECHNICAL DATA EPITAXIAL PLANAR NPN TRANSISTOR
SWITCHING APPLICATION.
INTERFACE CIRCUIT AND DRIVER CIRCUIT APPLICATION.
E
L B L
FEATURES
DIM MILLIMETERS
With Built-in Bias Resistors. A _
2.93 + 0.20
B 1.30+0.20/-0.15
Simplify Circuit Design. C 1.30 MAX
D
2 3 D 0.40+0.15/-0.05
Reduce a Quantity of Parts and Manufacturing Process.
A
G
E 2.40+0.30/-0.20
H
1 G 1.90
H 0.95
J 0.13+0.10/-0.05
K 0.00 ~ 0.10
Q
L 0.55
P P
M 0.20 MIN
N 1.00+0.20/-0.10
N
C
P 7
J
EQUIVALENT CIRCUIT BIAS RESISTOR VALUES Q 0.1 MAX
K
M
TYPE NO. R1(k ) R2(k )
OUT
KRC101S 4.7 4.7 1. COMMON (EMITTER)
2. IN (BASE)
R1 KRC102S 10 10
IN 3. OUT (COLLECTOR)
R2 KRC103S 22 22
KRC104S 47 47
COMMON
KRC105S 2.2 47 SOT-23
KRC106S 4.7 47
MAXIMUM RATING (Ta=25 )
CHARACTERISTIC SYMBOL RATING UNIT
Output Voltage KRC101S 106S VO 50 V
KRC101S 20, -10
KRC102S 30, -10
KRC103S 40, -10
Input Voltage VI V
KRC104S 40, -10
KRC105S 12, -5
KRC106S 20, -5
Output Current IO 100 mA
Power Dissipation PD 200 mW
KRC101S 106S
Junction Temperature Tj 150
Storage Temperature Range Tstg -55 150
Marking
TYPE KRC101S KRC102S KRC103S KRC104S KRC105S KRC106S Lot No.
MARK NA NB NC ND NE NF Type Name
2008. 10. 28 Revision No : 3 1/6
KRC101S~KRC106S
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Output Cut-off Current KRC101S 106S IO(OFF) VO=50V, VI=0 - - 500 nA
KRC101S 30 55 -
KRC102S 50 80 -
KRC103S 70 120 -
DC Current Gain GI VO=5V, IO=10mA
KRC104S 80 200 -
KRC105S 80 200 -
KRC106S 80 200 -
Output Voltage KRC101S 106S VO(ON) IO=10mA, II=0.5mA - 0.1 0.3 V
KRC101S - 1.5 2.0
KRC102S - 1.8 2.4
KRC103S - 2.1 3.0
Input Voltage (ON) VI(ON) VO=0.2V, IO=5mA V
KRC104S - 2.8 5.0
KRC105S - 0.8 1.1
KRC106S - 0.9 1.3
KRC101S 104S 1.0 1.2 -
Input Votlage (OFF) VI(OFF) VO=5V, IO=0.1mA V
KRC105S 106S 0.5 0.65 -
Transition Frequency KRC101S 106S fT * VO=10V, IO=5mA - 200 - MHz
KRC101S - - 1.8
KRC102S - - 0.88
KRC103S - - 0.36
Input Current II VI=5V mA
KRC104S - - 0.18
KRC105S - - 3.6
KRC106S - - 1.8
KRC101S 3.29 4.7 6.11
KRC102S 7 10 13
KRC103S 15.4 22 28.6
Input Resistor R1 - k
KRC104S 32.9 47 61.1
KRC105S 1.54 2.2 2.86
KRC106S 3.29 4.7 6.11
KRC101S~104S 0.8 1.0 1.2
Resistor Ratio KRC105S R2/R1 - 17 21 26
KRC106S 8 10 12
Note : * Characteristic of Transistor Only.
2008. 10. 28 Revision No : 3 2/6
KRC101S~KRC106S
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
KRC101S - 0.03 -
KRC102S - 0.05 -
KRC103S - 0.12 -
Rise Time tr
KRC104S - 0.22 -
KRC105S - 0.01 -
KRC106S - 0.03 -
KRC101S - 2.0 -
KRC102S - 2.0 -
VO=5V
Switching KRC103S - 2.0 -
Storage Time tstg VIN=5V S
Time KRC104S - 2.0 -
RL=1k
KRC105S - 2.0 -
KRC106S - 2.0 -
KRC101S - 0.12 -
KRC102S - 0.36 -
KRC103S - 0.35 -
Fall Time tf
KRC104S - 0.6 -
KRC105S - 0.1 -
KRC106S - 0.19 -
2008. 10. 28 Revision No : 3 3/6
KRC101S~KRC106S
I O - VI(ON) I O - VI(ON)
KRC101S KRC102S
100 100
VO =0.2V 25 VO =0.2V
OUTPUT CURRENT I O (mA)
OUTPUT CURRENT I O (mA)
50 -25 50
30 100 30
10 10
Ta=25 C
00 C
5 5
C
Ta=-25 C Ta=25 C
00
3 3
Ta=1
Ta=1
Ta=-25 C
1 1
0.5 0.5
0.3 0.3
0.1 0.3 1 3 10 30 100 0.1 0.3 1 3 10 30 100
INPUT ON VOLTAGE V I(ON) (V) INPUT ON VOLTAGE V I(ON) (V)
I O - VI(ON) I O - VI(ON)
KRC103S KRC104S
100 100
VO =0.2V VO =0.2V
OUTPUT CURRENT I O (mA)
OUTPUT CURRENT I O (mA)
50 50
30 30
10 10
0 C
C
5 5
00
Ta=25 C Ta=25 C
10
3 3 =1
Ta=
Ta=-25 C
Ta
Ta=-25 C
1 1
0.5 0.5
0.3 0.3
0.1 0.3 1 3 10 30 100 0.1 0.3 1 3 10 30 100
INPUT ON VOLTAGE V I(ON) (V) INPUT ON VOLTAGE V I(ON) (V)
I O - V I(ON) I O - VI(ON)
KRC105S KRC106S
100 100
VO =0.2V VO =0.2V
OUTPUT CURRENT I O (mA)
OUTPUT CURRENT I O (mA)
50 50
30 30
10 10
00 C
00 C
5 5
Ta=25 C
Ta=1
Ta=1
3 3 Ta=25 C
Ta=-25 C Ta=-25 C
1 1
0.5 0.5
0.3 0.3
0.1 0.3 1 3 10 30 100 0.1 0.3 1 3 10 30 100
INPUT ON VOLTAGE V I(ON) (V) INPUT ON VOLTAGE V I(ON) (V)
2008. 10. 28 Revision No : 3 4/6
KRC101S~KRC106S
I O - VI(OFF) I O - V I(OFF)
KRC101S KRC102S
10k 10k
VO =5V VO =5V
5k 5k
