Image preview - the first page of the document
krc119s


>> Download krc119s documenatation <<

Text preview - extract from the document
                                    SEMICONDUCTOR                                                                       KRC119S
                                             TECHNICAL DATA                                          EPITAXIAL PLANAR NPN TRANSISTOR


  SWITCHING APPLICATION.
  INTERFACE CIRCUIT AND DRIVER CIRCUIT APPLICATION

  FEATURES
                                                                                                                                 E
    With Built-in Bias Resistors.                                                                                       L        B            L
                                                                                                                                                        DIM   MILLIMETERS
    Simplify Circuit Design.                                                                                                                             A            _
                                                                                                                                                                 2.93 + 0.20
    Reduce a Quantity of Parts and Manufacturing Process.                                                                                                B    1.30+0.20/-0.15
                                                                                                                                                         C       1.30 MAX




                                                                                                                                                  D
                                                                                                                        2                     3          D    0.40+0.15/-0.05




                                                                                                       A

                                                                                                            G
                                                                                                                                                         E    2.40+0.30/-0.20




                                                                                                                    H
                                                                                                                        1                                G          1.90
                                                                                                                                                         H          0.95
                                                                                                                                                         J    0.13+0.10/-0.05
  EQUIVALENT CIRCUIT                            BIAS RESISTOR VALUES                                                                                     K      0.00 ~ 0.10
                                                                                                      Q
                                                                                                                                                         L           0.55
                                                      TYPE NO.                                                              P             P
                                                                    R1(k )      R2(k      )                                                              M       0.20 MIN
                             OUT                                                                                                                         N    1.00+0.20/-0.10
                                                      KRC119S            4.7         10




                                                                                                                    N
                                                                                                                C
                                                                                                                                                         P            7




                                                                                                                                                  J
                                                                                                                                                         Q         Max 0.1.




                                                                                                                            K
                                                                                                                                      M
               R1
      IN
                        R2



                         COMMON
                                                                                                                                SOT-23



  MAXIMUM RATING (Ta=25                  )
        CHARACTERISTIC                    SYMBOL                   RATING                     UNIT
  Output Voltage                             VO                       50                       V
                                                                                                                 Marking
  Input Voltage                                 VI                   25, -7                    V
                                                                                                                                                                    Lot No.
  Output Current                                IO                    150                     mA
  Power Dissipation                             PD                    200                     mW            Type Name
                                                                                                                                     N6
  Junction Temperature                          Tj                    150
  Storage Temperature Range                  Tstg                  -55 150




  ELECTRICAL CHARACTERISTICS (Ta=25 )
           CHARACTERISTIC                    SYMBOL                      TEST CONDITION                    MIN.             TYP.                      MAX.          UNIT
   Output Cut-off Current                       IO(OFF)          VO=50V, VI=0                               -                    -                    500             nA
   DC Current Gain                                   GI          VO=5V, IO=10mA                             30                   -                      -
   Output Voltage                               VO(ON)           IO=10mA, II=0.5mA                          -                   0.1                    0.3             V
   Input Voltage (ON)                           VI(ON)           VO=0.3V, IO=20mA                           -               1.76                       2.5             V
   Input Voltage (OFF)                          VI(OFF)          VCC=5V, IO=100 A                          0.3              0.82                        -              V
   Transition Frequency                              f T*        VO=10V, IO=5mA                             -                   250                     -           MHz
   Input Current                                      II         VI=5V                                      -                    -                     1.8           mA
   Input Resistor                                    R1                          -                         3.29                 4.7                   6.11           k
   Resistor Ratio                               R2/R1                            -                         1.7                  2.1                    2.6

  Note : * Characteristic of Transistor Only.


2012. 8. 24                        Revision No : 0                                                                                                                              1/2
                                                                                       KRC119S


                                                      I O - V I(ON)                                                                                 I O - V I(OFF)
                               100                                                                                        3k
                                50




                                                                                               OUTPUT CURRENT I O (
