Image preview - the first page of the document
>> Download krc651f documenatation <<
Text preview - extract from the document
SEMICONDUCTOR KRC651F~KRC654F
TECHNICAL DATA EPITAXIAL PLANAR NPN TRANSISTOR
SWITCHING APPLICATION.
INTERFACE CIRCUIT AND DRIVER CIRCUIT APPLICATION.
B
FEATURES
B1
With Built-in Bias Resistors.
Simplify Circuit Design.
Reduce a Quantity of Parts and Manufacturing Process.
C
DIM MILLIMETERS
A1
A
High Packing Density. A _
1.0 + 0.05
C
A1 _
0.7 + 0.05
Thin Fine Pitch Super mini 5 pin Package. _
D
B 1.0 + 0.05
B1 _
0.8 + 0.05
C 0.35
D _
0.15 + 0.05
H 0.38+0.02/-0.04
_
H
T 0.1 + 0.05
T
EQUIVALENT CIRCUIT BIAS RESISTOR VALUES
TYPE NO. R1(k ) R2(k )
OUT 1. Q 1 IN (BASE)
2. Q 1, Q 2 COMMON (EMITTER)
KRC651F 4.7 4.7 3. Q 2 IN (BASE)
R1 4. Q 2 OUT (COLLECTOR)
KRC652F 10 10 5. Q 1 OUT (COLLECTOR)
IN
R2 KRC653F 22 22
KRC654F 47 47 TFSV
COMMON
EQUIVALENT CIRCUIT (TOP VIEW)
5 4
Q1 Q2
1 2 3
MAXIMUM RATING (Ta=25 )
CHARACTERISTIC SYMBOL RATING UNIT
Output Voltage VO 20 V
Input Voltage VI 10/-10 V
Output Current IO 50 mA
KRC651F 654F
Power Dissipation PD* 50 mW
Junction Temperature Tj 150
Storage Temperature Range Tstg 55 150
* Total Rating.
Marking Type Name
5 4
MARK SPEC
TYPE KRC651F KRC652F KRC653F KRC654F
MARK JA JB JC JD
1 2 3
2008. 11. 20 Revision No : 2 1/5
KRC651F~KRC654F
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Output Cut-off Current KRC651F 654F IO(OFF) VO=20V, VI=0 - - 500 nA
KRC651F 30 - -
KRC652F 60 - -
DC Current Gain GI VO=5V, IO=10mA
KRC653F 100 - -
KRC654F 120 - -
Output Voltage KRC651F 654F VO(ON) IO=5mA, II=0.25mA - - 0.15 V
KRC651F - - 2.0
KRC652F - - 2.2
Input Voltage (ON) VI(ON) VO=0.2V, IO=5mA V
KRC653F - - 2.7
KRC654F - - 3.6
Input Voltage (OFF) KRC651F 654F VI(OFF) VO=5V, IO=0.1mA 0.8 - 1.5 V
KRC651F - - 1.8
KRC652F - - 0.88
Input Current II VI=5V mA
KRC653F - - 0.36
KRC654F - - 0.18
KRC651F 3.29 4.7 6.11
KRC652F 7 10 13
Input Resistor R1 - k
KRC653F 15.4 22 28.6
KRC654F 32.9 47 61.1
Resistor Ratio KRC651F 654F R2/R1 - 0.8 1.0 1.2
2008.. 11. 20 Revision No : 2 2/5
KRC651F~KRC654F
IO - VI(ON) IO - VI(OFF)
KRC651F KRC651F
100 10000
VO= 0.2V VO= 5V
OUTPUT CURRENT IO (mA)
OUTPUT CURRENT IO (mA)
1000
10
Ta =100 C
100
Ta =25 C 100 C 25 C -25 C
Ta =-25 C
1 10
0.1 1 10 100 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
INPUT ON VOLTAGE VI(ON) (V) INPUT OFF VOLTAGE VI(OFF) (V)
GI - IO VO(ON) - IO
KRC651F KRC651F
1000 1.00
VO= 5V GI= 20
OUTPUT ON VOLTAGE (V)
DC CURRENT GAIN GI
100 Ta =100 C
Ta =100 C
Ta =25 C 0.10
Ta =-25 C
Ta =25 C
10
Ta =-25 C
1 0.01
1 10 100 1 10 100
OUTPUT CURRENT IO (mA) OUTPUT CURRENT IO (mA)
IO - VI(ON) IO - VI(OFF)
KRC652F KRC652F
100 10000
VO= 0.2V VO= 5V
OUTPUT CURRENT IO (mA)
OUTPUT CURRENT IO (mA)
1000
C
10
100
-25 C
25 C
Ta =
Ta =
Ta =
100
Ta =100 C
Ta =25 C
Ta =-25 C
1 10
1 10 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
INPUT ON VOLTAGE VI(ON) (V) INPUT OFF VOLTAGE VI(OFF) (V)
2008.. 11. 20 Revision No : 2 3/5
KRC651F~KRC654F
GI - IO VO(ON) - IO
KRC652F KRC652F
1000 1.00
VO= 5V GI= 20
OUTPUT ON VOLTAGE (V)
Ta =100 C
DC CURRENT GAIN GI
100 Ta =100 C
Ta =25 C
Ta =-25 C 0.10
Ta =25 C
10 Ta =-25 C
1 0.01
1 10 100 1 10 100
OUTPUT CURRENT IO (mA) OUTPUT CURRENT IO (mA)
IO - VI(ON) IO - VI(OFF)
KRC653F KRC653F
100 1000
VO= 0.2V VO= 5V
OUTPUT CURRENT IO (mA)
OUTPUT CURRENT IO (mA)
100
10
C
100
25 C
-25 C
Ta =
10
Ta =
Ta =
Ta =100 C
Ta =25 C
Ta =-25 C
1 1
0.1 1 10 100 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
INPUT ON VOLTAGE VI(ON) (V) INPUT OFF VOLTAGE VI(OFF) (V)
GI - IO VO(ON) - IO
KRC653F KRC653F
100 1.00
VO= 0.2V GI= 20
OUTPUT ON VOLTAGE (V)
Ta =100 C
DC CURRENT GAIN GI
10 Ta =25 C
Ta =-25 C Ta =100 C
0.10
1 Ta =25 C
Ta =-25 C
0.1 0.01
1 10 100 1 10 100
OUTPUT CURRENT IO (mA) OUTPUT CURRENT IO (mA)
2008.. 11. 20 Revision No : 2 4/5
KRC651F~KRC654F
IO - VI(ON) IO - VI(OFF)
KRC654F KRC654F
100 10000
VO= 0.2V VO= 5V
OUTPUT CURRENT IO (mA)
OUTPUT CURRENT IO (mA)
1000
C
00
Ta =100 C
C
=1
=25
10
Ta
C
-25
Ta
Ta =
100
Ta =25 C
Ta =-25 C
1 10
0.1 1 10 100 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
INPUT ON VOLTAGE VI(ON) (V) INPUT OFF VOLTAGE VI(OFF) (V)
GI - IO VO(ON) - IO
KRC654F KRC654F
1000 1.00
VO= 0.2V GI= 20
OUTPUT ON VOLTAGE (V)
Ta =100 C
DC CURRENT GAIN GI
Ta =25 C Ta =100 C
100 Ta =-25 C 0.10
Ta =25 C
Ta =-25 C
10 0.01
1 10 100 1 10 100
OUTPUT CURRENT IO (mA) OUTPUT CURRENT IO (mA)
2008.. 11. 20 Revision No : 2 5/5
