Image preview - the first page of the document
>> Download tip41cf documenatation <<
Text preview - extract from the document
SEMICONDUCTOR TIP41CF
TECHNICAL DATA EPITAXIAL PLANAR NPN TRANSISTOR
GENERAL PURPOSE APPLICATION.
A C
FEATURES
DIM MILLIMETERS
F
Complementary to TIP42CF. S
A _
10.0 + 0.3
P
B _
15.0 + 0.3
E
C _
2.70 + 0.3
B
D 0.76+0.09/-0.05
G
E 3.2 + 0.2
_
F _
3.0 + 0.3
G _
12.0 + 0.3
MAXIMUM RATING (Ta=25 ) H 0.5+0.1/-0.05
L L J _
13.6 + 0.5
CHARACTERISTIC SYMBOL RATING UNIT
K
R _
K 3.7 + 0.2
L 1.2+0.25/-0.1
Collector-Base Voltage VCBO 100 V M
M 1.5+0.25/-0.1
J
D D N _
2.54 + 0.1
Collector-Emitter Voltage VCEO 100 V P _
6.8 + 0.1
Q _
4.5 + 0.2
Emitter-Base Voltage VEBO 5 V R _
2.6 + 0.2
N N H S 0.5 Typ
DC IC 6
Collector Current A
Pulse ICP 10
1. BASE
Q
Base Current IB 2 A 1 2 3
2. COLLECTOR
Collector Power Ta=25 2 W 3. EMITTER
PC
Dissipation Tc=25 25 W
Junction Temperature Tj 150
TO-220IS
Storage Temperature Range Tstg -55 150
ELECTRICAL CHARACTERISTICS (Ta=25 )
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Collector Emitter Sustaining Voltage VCEO(SUS) IC=30mA, IB=0 100 - - V
Collector Cut-off Current ICEO VCE=60V, IB=0 - - 0.7 mA
Collector Cut-off Current ICES VCE=100V, VEB=0 - - 400 A
Emitter Cut-off Current IEBO VEB=5V, IC=0 - - 1 mA
VCE=4V, IC=0.3A 30 - -
DC Current Gain hFE
VCE=4V, IC=3A 15 - 75
Collector-Emitter Saturation Voltage VCE(sat) IC=6A, IB=600mA - - 1.5 V
Base-Emitter On Voltage VBE(on) VCE=4V, IC=6A - - 2.0 V
Transition Frequency fT VCE=10V, IC=500mA 3.0 - - MHz
2007. 5. 21 Revision No : 0 1/2
TIP41CF
h FE - I C V CE(sat) , VBE(sat) - I C
1k 10k
VCE =4V I C /I B =10
300 3k
SATURATION VOLTAGE
DC CURRENT GAIN h FE
VCE(sat) ,V BE(sat) (mV)
100 1k VBE(sat)
30 300
10 100
3 30 VCE(sat)
1 10
1 3 10 30 100 300 1k 3k 10k 1 3 10 30 100 300 1k 3k 10k
COLLECTOR CURRENT I C (mA) COLLECTOR CURRENT I C (mA)
P C - Ta SAFE OPERATING AREA
COLLECTOR POWER DISSIPATION PC (W)
30 30
COLLECTOR CURRENT I C (A)
25 I C MAX.(PULSE) *
10
I C MAX.
0.5
1m
20 (CONTIN
5m
mS
S
3 -UOUS) DC
S
* *
OP *
15 ER
AT
IN
1 G
10 * SINGLE NONREPETITIVE
PULSE Tc=25 C
0.3 CURVES MUST BE DERATED
5 LINEARLY WITH INCREASE
IN TEMPERATURE
0 0.1
0 50 100 150 200 1 3 10 30 100 300
AMBIENT TEMPERATURE Ta ( C) COLLECTOR-EMITTER VOLTAGE VCE (V)
2007.5. 21 Revision No : 0 2/2
