                     DTA114EE/DTA114EUA/DTA114EKA /DTA114ESA/DTA114ECA

Digital transistors (PNP)
1. Built-in bias resistors enable the configuration of an inverter circuit
   without connecting external input resistors(see equivalent circuit).
2. The bias resistors consist of thin-film resistors with complete isolation
   to allow positive biasing of the input.They also have the advantage of
   almost completely eliminating parasitic effects.
3. Only the on/off conditions need to be set for operation, making device
   design easy.


     DTA114EE                                              DTA114EUA

     SOT-523     Addreviated symbol: 14
                                                                         Addreviated symbol: 14

     DTA114EKA                                             DTA114ECA

                                                           SOT-23            Addreviated symbol: 14
                     Addreviated symbol: 14





                       DTA114EE/DTA114EUA/DTA114EKA /DTA114ESA/ DTA114ECA
Absolute maximum ratings(Ta=25)
                                                                Limits (DTA114E)
         Parameter          Symbol                                                                                   Unit
                                               E           UA             CA           KA             SA
       Supply voltage          VCC                                        -50                                         V
        Input voltage           VIN                                     -40~10                                        V
                                   IO                                     -50
       Output current                                                                                                mA
                             IC(MAX)                                     -100
      Power dissipation            Pd          150                       200                         300             mW
 Junction temperature              Tj                                    150
 Storage temperature           Tstg                                     -55~150
Electrical characteristics (Ta=25)
        Parameter          Symbol       Min.         Typ        Max.            Unit            Conditions
                            VI(off)                             -0.5                        VCC=-5V ,IO=-100
