Image preview - the first page of the document



>> Download dta123yca documenatation <<

Text preview - extract from the document

                 DTA123YE/DTA123YUA/DTA123YCA/DTA123YKA/DTA123YSA


DIGITAL TRANSISTOR(PNP)


 DIGITAL TRANSISTOR (PNP)
Features
1) Built-in bias resistors enable the configuration of an inverter circuit
   without connecting external input resistors (see equivalent circuit).
2) The bias resistors consist of thin-film resistors with complete isolation
   to allow positive biasing of the input. They also have the advantage of
   almost completely eliminating parasitic effects.
3) Only the on/off conditions need to be set for operation, making device design easy.



PIN CONNENCTIONS AND MARKING

 DTA123YE                                                DTC114EUA
                                                         DTA123YUA




                                                         SOT-323

 SOT-523       Addreviated symbol: 52                                     Addreviated symbol: 52



 DTA123YKA                                               DTA123YCA




                                                         SOT-23
 SOT-23-3L
                   Addreviated symbol: 52                               Addreviated symbol: 52




 DTA123YSA




     TO-92S




 1




 JinYu                                      www.htsemi.com
 semiconductor
                                                                                                 Date:2011/05
                       DTA123YE/DTA123YUA/DTA123YCA/DTA123YKA/DTA123YSA
Absolute maximum ratings(Ta=25)
                                                               Limits (DTA123Y )
        Parameter          Symbol                                                                                    Unit
                                              E           UA             KA           CA             SA
      Supply voltage          VCC                                        -50                                          V
       Input voltage          VIN                                       -12~5                                         V
                                  IO                                    -100
      Output current                                                                                                 mA
                            IC(MAX)                                     -100
 Power dissipation            Pd             150                        200                          300             mW
         Junction
                                  Tj                                    150
       temperature
Storage temperature          Tstg                                      -55~150
Electrical characteristics (Ta=25)
        Parameter          Symbol      Min.         Typ         Max.           Unit            Conditions
                           VI(off)                              -0.3                       VCC=-5V ,IO=-100
