                  DTA123JE/DTA123JUA/DTA123JKA/DTA123JCA/DTA123JSA


TRANSISTOR(PNP)
Features
1) Built-in bias resistors enable the configuration of an inverter circuit
   without connecting external input resistors(see equivalent circuit).
2) The bias resistors consist of thin-film resistors with complete isolation
   to allow positive biasing of the input. They also have the advantage of
   almost completely eliminating parasitic effects.
3) Only the on/off conditions need to be set for operation, making device
   design easy.




PIN CONNENCTIONS AND MARKING

 DTA123JE                                                  DTA123JUA




     SOT-523     Addreviated symbol: E32                      SOT-323
                                                                           Addreviated symbol: 132


                                                           DTA114ECA
                                                           DTA123JCA
 DTA123JKA


   SOT-23
 SOT-23-3L

                   Addreviated symbol: E32                 SOT-23        Addreviated symbol: E32



 DTA123JSA




 TO-92S




 1




 JinYu                                       www.htsemi.com
 semiconductor
                                                                                                   Date:201/5
                       DTA123JE/DTA123JUA/DTA123JKA/DTA123JCA/DTA123JSA
 Absolute maximum ratings(Ta=25)
                                                                    Limits (DTA123J      )
           Parameter         Symbol                                                                                        Unit
                                                   E           UA             KA             CA               SA
 Supply voltage                     VCC                                       -50                                           V
 Input voltage                      VIN                                     -12~+5                                          V
                                    IO                                       -100
 Output current                                                                                                            mA
                                 IC(MAX)                                     -100
 Power dissipation                  Pd            150                        200                              300          mW
 Junction temperature               Tj                                       150
 Storage temperature              Tstg                                      -55~150
 Electrical characteristics (Ta=25)

        Parameter        Symbol            Min.         Typ         Max.        Unit                 Conditions
                          VI(off)                                    -0.5                     VCC=-5V, IO=-100
