Image preview - the first page of the document
dtc124eca


>> Download dtc124eca documenatation <<

Text preview - extract from the document
                DTC124EE/DTC124EUA/DTC124ECA/DTC124EKA/DTC124ESA


DIGITAL TRANSISTOR (NPN)
Features
1. Built-in bias resistors enable the configuration of an inverter circuit without
   connecting external input resistors(see equivalent circuit).
2. The bias resistors consist of thin-film resistors with complete isolation to
   allow negative biasing of the input. They also have the advantage of
    almost completely eliminating parasitic effects.
3. Only the on/off conditions need to be set for operation, making device
    design easy.


PIN CONNENCTIONS AND MARKING

 DTC124EE                                                    DTC124EUA




     SOT-523        Addreviated symbol: 25                      SOT-323      Addreviated symbol: 25


                                                             DTA114ECA
                                                             DTC124ECA
 DTC124EKA


   SOT-23
 SOT-23-3L
                      Addreviated symbol: 25                 SOT-23        Addreviated symbol: 25



 DTC124ESA




 TO-92S




 1




 JinYu                                         www.htsemi.com
 semiconductor

                                                                                                      Date:2011/05
                      DTC124EE/DTC124EUA/DTC124ECA/DTC124EKA/DTC124ESA
 Absolute maximum ratings(Ta=25)
                                                                   Limits (DTC124E   )
Parameter                     Symbol                                                                                      Unit
                                                     E          UA          KA           CA                         SA
Supply voltage                       VCC                                     50                                            V
Input voltage                        VIN                                  -10~40                                           V
                                      IO                                     30
Output current                                                                                                            mA
                                  IC(MAX)                                   100
Power dissipation                   Pd              150                     200                                     300   mW
Junction temperature                 Tj                                     150
Storage temperature                Tstg                                  -55~150

 Electrical characteristics (Ta=25)

        Parameter         Symbol            Min.          Typ       Max.    Unit               Conditions
                           VI(off)                                  0.5                   VCC=5V, IO=100
