Image preview - the first page of the document
ktc3265


>> Download ktc3265 documenatation <<

Text preview - extract from the document
                                                                                                                                       KTC3265


    TRANSISTOR (NPN)                                                                               SOT-23


    FEATURES
                                                                                                   1. BASE
                                                                                                   2. EMITTER
              High DC current gain
                                                                                                   3. COLLECTOR
              Complementary to KTA1298



    MAXIMUM RATINGS (TA=25 unless otherwise noted)

            Symbol                 Parameter                        Value                  Units
     VCBO              Collector-Base Voltage                         35                    V
     VCEO              Collector-Emitter Voltage                      30                    V
     VEBO              Emitter-Base Voltage                           5                     V
     IC                Collector Current -Continuous                 800                   mA
     PC                Collector Power Dissipation                   200                   mW
     Tj                Junction Temperature                          150
     Tstg              Storage Temperature                          -55-150

    ELECTRICAL CHARACTERISTICS (Tamb=25 unless otherwise specified)

                 Parameter                             Symbol          Test   conditions             MIN          TYP                  MAX    UNIT

     Collector-base breakdown voltage                  V(BR)CBO      IC= 100A, IE=0                   35                                       V

     Collector-emitter breakdown voltage               V(BR)CEO      IC= 10mA, IB=0                   30                                       V

     Emitter-base breakdown voltage                    V(BR)EBO      IE=100A, IC=0                     5                                       V

     Collector cut-off current                           ICBO        VCB=30 V, IE=0                                                     0.1    A
     Collector cut-off current                           IEBO        VEB=5 V, IC=0                                                      0.1    A
     DC current gain                                     hFE         VCE=1V, IC= 100mA                100                               320

     Collector-emitter saturation voltage              VCE(sat)      IC=500mA, IB=20mA                                                  0.5    V

     base-emitter voltage                               V BE         VCE=1V,IC=10mA                   0.5                               0.8    V

                                                                     VCE=5V, IC=10mA
     Transition frequency                                 fT                                                      120                         MHz
                                                                     f=100MHz
     Collector output capacitance                        Cob         VCB=10V,IE=0,f=1MHZ                           13                          pF

    CLASSIFICATION OF            hFE
    Rank                                                        O                                                 Y
    Range                                                100-200                                             160-320
    Marking                                                    EO                                                 EY



1




JinYu                                           www.htsemi.com
semiconductor

                                                                                                                        Date:2011/05
                                                          KTC3265

Typical Characteristics




 2




JinYu                     www.htsemi.com
semiconductor

                                           Date:2011/05
