Image preview - the first page of the document
ss8050


>> Download ss8050 documenatation <<

Text preview - extract from the document
                                                                                                                                SS8 050


TRANSISTOR(NPN)                                                                          SOT-23


                                                                                         1. BASE
FEATURES
                                                                                         2. EMITTER
Complimentary to SS8550                                                                  3. COLLECTOR



MARKING: Y1

MAXIMUM RATINGS (TA=25 unless otherwise noted)

            Symbol                                 Parameter                              Value                                  Units
     VCBO              Collector-Base Voltage                                                 40                                      V
     VCEO              Collector-Emitter Voltage                                              25                                      V
     VEBO              Emitter-Base Voltage                                                    5                                      V
     IC                Collector Current -Continuous                                          1.5                                     A
     PC                Collector Power Dissipation                                            0.3                                     W
     Tj                Junction Temperature                                                   150
     Tstg              Storage Temperature                                               -55-150

ELECTRICAL CHARACTERISTICS (Tamb=25  unless otherwise specified)

                 Parameter                             Symbol       Test    conditions   MIN          TYP                   MAX           UNIT

     Collector-base breakdown voltage                  V(BR)CBO   IC= 100A, IE=0         40                                                V

     Collector-emitter breakdown voltage               V(BR)CEO   IC= 0.1mA, IB=0        25                                                V

     Emitter-base breakdown voltage                    V(BR)EBO   IE=100A, IC=0           5                                                V

     Collector cut-off current                           ICBO     VCB=40V, IE=0                                                 0.1       A

     Collector cut-off current                           ICEO     VCB=20V, IE=0                                                 0.1       A

     Emitter cut-off current                             IEBO     VEB= 5V, IC=0                                                 0.1       A

                                                        hFE(1)    VCE=1V, IC= 100mA      120                                    400
     DC current gain
                                                        hFE(2)    VCE=1V, IC= 800mA      40

     Collector-emitter saturation voltage              VCE(sat)   IC=800mA, IB= 80mA                                            0.5        V

     Base-emitter saturation voltage                   VBE(sat)   IC=800mA, IB= 80mA                                            1.2        V

                                                                  VCE=10V, IC= 50mA
     Transition frequency                                 fT                             100                                              MHz
                                                                  f=30MHz

CLASSIFICATION OF hFE(1)
     Rank                                     L                                   H                                         J
     Range                               120-200                            200-350                         300-400


 1




 JinYu                                             www.htsemi.com
 semiconductor

                                                                                                             Date:2011/05
                                                                                                                                                                                                                                                              SS8 050


                                                             0.5                                                                                                            1000

                                                                                                                                                                                                                                      VCE = 1V
                                                                                                       IB = 3.0mA
                           IC[A], COLLECTOR CURRENT




                                                             0.4




                                                                                                                                                     hFE, DC CURRENT GAIN
                                                                                                       IB = 2.5mA
                                                                                                                                                                            100
                                                             0.3                                       IB = 2.0mA


                                                                                                       IB = 1.5mA
                                                             0.2
                                                                                                                                                                              10
                                                                                                       IB = 1.0mA
                                                             0.1

                                                                                                       IB = 0.5mA

                                                                                                                                                                               1
                                                                   0    0.4          0.8         1.2      1.6                2.0                                                0.1                1              10          100                          1000


                                                                       VCE[V], COLLECTOR-EMITTER VOLTAGE                                                                                          IC[mA], COLLECTOR CURRENT
          VBE(sat), VCE(sat)[mV], SATURATION VOLTAGE




                                                            10000                                                                                                            100

                                                                                                                IC = 10 IB                                                                                                            VCE = 1V
                                                                                                                                               IC[mA], COLLECTOR CURRENT




                                                                              VBE(sat)
                                                             1000                                                                                                             10




                                                              100                                                                                                              1


                                                                              VCE(sat)




                                                               10                                                                                                             0.1
                                                                 0.1          1             10          100                  1000                                                0.0        0.2        0.4        0.6   0.8           1.0                   1.2


                                                                          IC[mA], COLLECTOR CURRENT                                                                                           VBE[V], BASE-EMITTER VOLTAGE




                                                            1000                                                                                                               1000
                                                                                                                                    CURRENT GAIN BANDWIDTH PRODUCT




                                                                                                           IE = 0                                                                                                                     VCE = 10V
                                                                                                           f = 1MHz
                                    Cob [pF], CAPACITANCE




                                                             100                                                                                                                100
                                                                                                                                                fT[MHz],




                                                              10                                                                                                                   10




                                                              1                                                                                                                    1
                                                                   1                       10                            100                                                            1                    10                     100                      400


                                                                       VCB [V], COLLECTOR-BASE VOLTAGE                                                                                             IC[mA], COLLECTOR CURRENT




2




JinYu                                                                                                  www.htsemi.com
semiconductor

                                                                                                                                                                                                                                            Date:2011/05
