HiPerFETTM                                                                                               VDSS        ID25         RDS(on)
Power MOSFETs                                                  IXFH/IXFM 35 N30                         300 V       35 A 100 mW
                                                               IXFH 40 N30                              300 V       40 A 85 mW
                                                               IXFM 40 N30                              300 V       40 A 88 mW
N-Channel Enhancement Mode
High dv/dt, Low trr, HDMOSTM Family                                                                     trr
