Image preview - the first page of the document
ixfh42n50p2_ixft42n50p2


>> Download ixfh42n50p2_ixft42n50p2 documenatation <<

Text preview - extract from the document
                                           Advance Technical Information

PolarP2TM HiperFETTM                               IXFH42N50P2                          VDSS       = 500V
Power MOSFET                                       IXFT42N50P2                          ID25       = 42A
                                                                                        RDS(on)     145m
N-Channel Enhancement Mode
Avalanche Rated
Fast Intrinsic Diode                                                                    TO-247 (IXFH)




                                                                                               G
Symbol       Test Conditions                              Maximum Ratings                          D               D (Tab)
                                                                                                       S
VDSS         TJ = 25
