HiPerFETTM                                                         IXFH 80N10Q                         VDSS              = 100 V
Power MOSFETs                                                      IXFT 80N10Q                         ID25              = 80  A
Q-Class                                                                                                RDS(on)           = 15 mW
N-Channel Enhancement Mode                                                                              trr
