HiPerFETTM                                             IXFN 80N50                                VDSS                 = 500 V
Power MOSFETs                                                                                    ID25                 = 80 A
Single Die MOSFET                                                                                RDS(on)              = 55 m
                                                                                        D        trr                   250 ns
N-Channel Enhancement Mode
Avalanche Rated, High dv/dt, Low trr                                    G


                                                                        S
                                                                                        S

Symbol         Test Conditions                                      Maximum Ratings              miniBLOC, SOT-227 B (IXFN)
                                                                                                      E153432
VDSS           TJ = 25
