PolarHTTM HiPerFET IXFR 140N20P                                                                         VDSS = 200 V
Power MOSFET                                                                                            ID25 = 90 A
                                                                                                        RDS(on)  22 m
ISOPLUS247TM
(Electrically Isolated Back Surface)                                                                     trr     200 ns
N-Channel Enhancement Mode
Fast Intrinsic Diode
Avalanche Rated
Symbol         Test Conditions                                     Maximum Ratings
                                                                                                  ISOPLUS247 (IXFR)
VDSS           TJ = 25
