Image preview - the first page of the document



>> Download ixfr48n60p documenatation <<

Text preview - extract from the document

PolarHVTM HiPerFET                                        IXFR 48N60P                             VDSS               = 600 V
Power MOSFET                                                                                       ID25              = 32 A
                                                                                                  RDS(on)             150 m
ISOPLUS247TM
(Electrically Isolated Back Surface)
                                                                                                    trr               200 ns
N-Channel Enhancement Mode
Avalanche Rated
Fast Intrinsic Diode

Symbol         Test Conditions                                     Maximum Ratings
                                                                                                  ISOPLUS247 (IXFR)
VDSS           TJ = 25
