Image preview - the first page of the document



>> Download ixgh60n60b2_ixgt60n60b2 documenatation <<

Text preview - extract from the document

                                                     Advance Technical Data


HiPerFASTTM IGBT                                         IXGH 60N60B2                          VCES                      = 600 V
                                                         IXGT 60N60B2                          IC25                      = 75 A
Optimized for 10-25 kHz hard                                                                   VCE(sat)                  < 1.8 V
switching and up to 100 KHz                                                                    tfi typ                   = 100 ns
resonant switching




Symbol           Test Conditions                                Maximum Ratings             TO-268
                                                                                             (IXGT)
VCES             TJ = 25
