Image preview - the first page of the document



>> Download ixgh72n60c3 documenatation <<

Text preview - extract from the document

GenX3TM 600V IGBT                                 IXGH72N60C3                          VCES             =    600V
                                                                                       IC110            =    72A
                                                                                       VCE(sat)              2.5V
High-Speed PT IGBT for                                                                 tfi (typ)        =    55ns
40-100kHz Switching



Symbol       Test Conditions                               Maximum Ratings             TO-247 AD
VCES         TJ = 25
