ixth11p50_ixtt11p50


>> Download ixth11p50_ixtt11p50 documenatation <<

Text preview - extract from the document
Standard Power MOSFET                                                                          VDSS         = -500 V
P-Channel Enhancement Mode                               IXTH 11P50                            ID25         = -11 A
Avalanche Rated
                                                         IXTT 11P50                            RDS(on)      = 0.75




Symbol         Test Conditions                                       Maximum Ratings           TO-247 AD (IXTH)
VDSS           TJ = 25
